Telemecanique Xcc1406pr10k Incremental Encoder ? 40 1000 Points - Push-pull.new

US $99.00

Riga, default, Latvia
Jun 9th

Open on mobile:
QR code

TELEMECANIQUE XCC1406PR10K incremental encoder ? 40 1000 points - push-pull.NEW Main Range of product OsiSense XCC Encoder type Incremental encoder Encoder name XCC Product specific application - Diameter 40 mm Shaft diameter 6 mm Shaft type Solid shaft Resolution 1000 points Output stage Type K Type of output stage Driver push-pull Electrical connection Cable radial shielded Cable length 2 m Cable composition 8 x 0.14 mm? [Us] rated supply voltage 11...30 V DC Enclosure material Aluminium Zamak Complementary Shaft tolerance G7 Cable outer diameter 6 mm Residual ripple 0...500 mV Maximum revolution speed 9000 rpm Shaft moment of inertia 10 g.cm? Torque value 0.002 N.m Maximum load 2 daN radial 1 daN axial Output frequency 100 kHz Number of channels 3 Current consumption 0...75 mA (no-load) Protection type Reverse polarity protection Short-circuit protection Maximum output current 40 mA Output level High level: V supply - 3 V minimum (20 mA) Low level: 1.5 V maximum (20 mA) Surge withstand 1 kV, level 2 conforming to IEC 61000-4-5 Base material Aluminium Zamak Shaft material Aluminium Stainless steel Type of ball bearings 688AZZ1 Product weight 0.355 kg Environment Marking CE Ambient air temperature for operation -20...80 °C Ambient air temperature for storage -30...85 °C IP degree of protection IP54 conforming to IEC 60529 Vibration resistance 10 gn (f = 10...500 Hz) conforming to IEC 60068-2-6 Shock resistance 30 gn for 11 ms conforming to IEC 60068-2-27 Resistance to electrostatic discharge 8 kV (air discharge) level 3 conforming to IEC 61000-4-2 4 kV (contact discharge) level 3 conforming to IEC 61000-4-2 Resistance to electromagnetic fields 10 V/m level 3 conforming to IEC 61000-4-3 Resistance to fast transients 2 kV (power ports) level 3 conforming to IEC 61000-4-4 1 kV (signal ports) level 3 conforming to IEC 61000-4-4 Offer Sustainability Sustainable offer status Not Green Premium product RoHS (date code: YYWW) Compliant - since 0701 - Schneider Electric declaration of conformity REACh Reference not containing SVHC above the threshold DELIVERY 10-12 DAYS TO AMERICADELIVERY 5-7 DAYS TO ENGLAND DELIVERY 4-6 DAYS TO EUROPE

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	TELEMECANIQUE
MPN	XCC1406PR10K
Model	XCC1406PR10K
Country/Region of Manufacture	France
