Telewave Tprd-0454 Pass/reject 40-50 Mhz Low Band Radio Duplexer

US $2,200.00

New York, New York, United States
Jun 9th

Open on mobile:
QR code

TeleWave TPRD-0454 Pass/Reject 40-50 MHz / ± 2.5 MHz Low band radio duplexer Receiver Frequency: Tuned to 48.98 MHz Transmitter Frequency: Tuned to 47:82 MHz International Buyers: We ship with fedex and UPS due to the size and weight of the item, however, I can probably get you a cheaper shipping rate with a 3rd party Shipping company, but delivery will take longer to arrive. Contact me for a quote to your area if you want us to ship the item with a 3rd party Shipping company . Description: The Telewave TPRD-0354 and TPRD-0454 allow the simultaneous operation of a transmitter and receiver into a common antenna. These duplexers feature minimum insertion loss, and maximum isolation between transmitter and receiver. The Pass-Reject design combines a bandpass response with a tunable notch at the RX frequency for improved performance at close spacing. The superior construction of Telewave cavity duplexers allows better rejection of transmitter spurious radiation, providing greater receiver protection. Selectivity and insertion loss are fully adjustable by rotating the calibrated connector loops. Telewave cavities are manufactured with 1/4 ” aluminum top plates, which are fully welded to the aluminum outer conductor. Silver plated tuners, beryllium copper finger stock contactors, and Attenuation in dB TYPICAL RESPONSE 20 80 60 40 0 -0.4 0 +0.4 TX-RX -0.2 +0.2 Frequency (MHz) threaded Invar tuning rods assure maximum temperature stability, higher “Q”, and years of trouble free operation. SPECS: Manufacturer Telewave, Inc. Mfg. Model No. TPRD-0454 Shipping Info LOCAL SHIPPING IS $150 ON THIS ITEM Product Description 40-50 MHz Pass/Rej. Duplexer Type Pass-Reject Freq. Range (MHz) 40-50 Application A duplexer is a device that will allow both a transmitter and a receiver to operate from a single antenna (freeing up tower space, and reducing cable runs etc.) Product Narrative Base station pass reject duplexer. RG214 interconnect cables. Min. Separation (MHz) 400 kHz min. Maximum Input (Watts) 350 Insertion Loss (Tx/Ant-dB) 1.5 Insertion Loss (Rx/Ant-dB) 1.5 Isolation Rx (Notch-dB) 80 Isolation Tx Side 80 Connectors N Female No. of Cavities/Size 4 (5") temp. Range deg-C -30 to +60 Maximum VSWR @ 50 Ohms 1.5 Tuning Method Factory Tune Size (HxWxD") 72x19x16 inches Finish Grey

“Very Good Condition! 'Send me your offer..”

Brand	Telewave
Band	Low Band
Model	TPRD-0454
Type	Duplexer
MPN	0454
