Telewave Twpc-1508-1 Bandpass Cavity Filter 148-174 Mhz

C $175.00

Kelowna, Canada
Aug 18th

Open on mobile:
QR code

Used Telewave TWPC-1508-1 Bandpass Cavity Filter 148-174 MHz Bandpass Cavity Filter Frequency Range: 148-174 MHz Currently tuned to: 149.11 MHz Insertion Loss: 0.5-2 dB VSWR: 1.5:1 Cavity Diameter: 8 Connectors: N Female From the Manufacturer - Product Description The Telewave TWPC-1508-1 Bandpass Cavity Filter 148-174 MHz, is 8” diameter, -wavelength, high “Q” bandpass cavity filters with superior selectivity. Bandpass cavities reject all frequencies outside a narrow pass band. These cavities reduce transmitter sideband noise, and also protect receivers against desensitization. TWPC-1508-1 cavities cover 148- 174 MHz. All cavities are tuned to specified frequencies prior to shipping, and no further adjustments should be required. The positive locking mechanism allows for quick field retuning if frequency changes become necessary. These cavities also feature calibrated adjustable coupling, and insertion loss can be easily set from 0.5 dB to 2 dB or more to improve selectivity. This allows cavity response to be optimized for any operating environment. Excellent frequency stability is achieved by the use of a specially machined compensator and Invar rod. The pass frequency is temperature stable from -30°C to +70°C. Telewave Ground Loop technology places the center conductor of each coupling loop at DC ground potential for lightning protection and noise reduction. Heavy duty materials are used throughout each cavity to insure high performance and long life. Cavity top plates are machined from -inch aluminum, and are heliarc welded to the cavity body at the high current point for improved conductivity and strength. This allows Telewave cavities to handle up to 350 watts, depending on insertion loss. Rigid foam inserts support the tuner assembly allowing vertical or horizontal mounting. Similar metals and alodined aluminum help prevent galvanic corrosion. Silver plated tuners and beryllium copper finger stock provide non-corrosive low loss contact, and ensure reliable, long-term performance.

“Cosmetic marks and scratches. Connectors show oxidization.”

Filter Type

Band Pass

Brand

Telewave

MPN

TWPC-1508-1
