Telex Bp-319 Rts Single-channel Portable Beltpack [intercom] Gray

US $203.00

Longwood, Florida, United States
Jan 29th

Open on mobile:
QR code

Seller Notes: I am a recently retired video professional. These belt packs are some of many intercom components I received instead of cash owed to me. They are new, never used and they have been in storage since received. I am now wanting to turn them into the cash I should have received. See my other listings for additional, compatible, Telex equipment to complete a four-station intercom setup (Power Supply, Belt Packs, Headsets, XLR Cables) Please contact me with any questions/concerns about this equipment. What is in this sale: Telex RTS BP-319 Single-Channel Portable Belt -Pack (Gray) in its original packaging User Manual OEM Description: The BP-319 is a portable user station for use with RTS TW (Two-Wire) intercom systems. It is a microprocessor controlled 1-channel intercom belt-pack. It has connections for headset/earset microphones (Dynamic or Electret). Call function allows the user to send or receive call signals to other devices on the intercom channel, including audible call alert on the listen side. Microprocessor controlled Microphone Kill Detect. Powered externally, via the intercom system power supply on channel 1. Headset 4- or 5-pin XLR connection set for intercom operation. Built-in auto-sensing headset connector that will determine automatically whether a dynamic or electret headset is connected to the system. OEM Specifications: GeneralPower Requirements: 30VDC nominal (standard RTS line), 45 to 70mA Environmental Requirements: Storage: -20°C to 80°C (-4°F to 176°F); 0% to 95% humidity, non-condensing Operating: 0°C to 50°C (32°F to 122°F); 0% to 95% humidity, non-condensing Dimensions: 5 in (127 mm) H, 3.5 in (88.9 mm) W, 1.8 in (45.7 mm) D Weight: 13 oz (364 g) approximately Interface Requirements Headset/Earset: 50 to 200? dynamic microphone 50 to 600? headphones RTS Intercom Channel: Output Level: 0.775Vrms (0 dBu) nominal Bridging Impedance: greater than 10k? Call Signalling: Send: 20kHz ±100Hz, 250mVrms ±10% Receive: 20kHz ±800Hz, 100mVrms Mic-Off Frequency Detect: 24kHz ±800Hz, 100mVrms Noise Contribution to 200? Intercom Line: -75 dBu Headphone Amplifier Maximum Output: 60mW into 150? Frequency Response: 200Hz to 8kHz +1/-3dB nominal Audible Alert: 1kHz tone Total Harmonic Distortion: Less than 0.2% nominal at 50mW from the line Sidetone: 20dB minimum range, adjustable Connector Pin Configurations Intercom Channel Connector XLR-3 M/F Pin 1 Common Pin 2 +30VDC In & audio Pin 3 Syst Chan 2 Headset Connector Type: XLR-4F Pin 1 Headset microphone low Pin 2 Headset microphone high Pin 3 Headphone low Pin 4 Headphone Chan 1 or Chan 1 and Chan 2 audio Type: XLR-5F Pin 1 Headset microphone low Pin 2 Headset microphone high Pin 3 Headphone low Pin 4 Headphone high Pin 5 No connection

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Beltpacks are new, never used. Original packaging has been opened. Includes user manual. Item will be in its original packaging.”
