Temperature, Depth, Submersible Data Logger Dst Centi-td

US $550.00

Reykjavik, default, Iceland
Feb 12th

Open on mobile:
QR code

The logger is sold as is and was manufactured in March 2014, the logger was calibrated at the time of manufacturing. We guarantee that the logger will be in working order but do not guarantee that the calibration accuracy be at specified values. The battery life is not 100%, feel free to e-mail us for exact battery life. You will need SeaStar software and a centi sized communication box. If you already own a communication box you can contact us with the serial number and we will verify compatibility. Check out our website to read the technical specifications that apply for newly manufactured http://www.star-oddi.com/products/4/temperature-depth-recorder/default.aspx Overview Dimensions (diameter x length): 15mm x 46mm Sensors: Depth(pressure), temperature Standard temperature range: -2°C to +40°C Temperature accuracy: +/-0.1°C Depth ranges: 10m-2000m Depth accuracy: +/-0.6% of selected range for 800m and 3000m range Memory size: 174,000 measurements per sensor Battery life: 9 years Housing material: Alumina (ceramic material) Description The DST centi-TD is a miniature temperature and depth recorder. Recorded data is stored in the logger‘s internal memory with a time stamp for each measurement. In SeaStar the user sets the start time, start date and sampling interval before starting the recorder. Fastest possible sampling interval is 0.1 second. Up to seven different intervals can be set for the same measurement sequence. This is especially useful when more frequent measurements are needed at a certain time period. With default programming temperature and depth are recorded as pairs, the two parameters can be set separately as primary and secondary parameters with different sampling frequency. That way memory partitioning can be customized according to individual preferences. After recovering the DST recorded data is uploaded to SeaStar where results are displayed both in graphic and tabular form. After retrieving the data, the DST can be re-programmed and reused as long as the battery lasts. DST centi-TD can be used as a stand-alone logger for recording depth and temperature in ocean and freshwater environments. The DST can be fastened to fishing gear, deployment lines, cables, moorings or other underwater equipment, collecting valuable data. The logger is also used for monitoring temperature and depth in geothermal boreholes. The shape of DST-centi TD is designed for tagging fish and marine animals, externally or internally with implantation providing information on fish behavior and migration. Examples of studies suitable for DST centi-TD: Fish and marine animal tagging Fisheries research Geothermal well logging Oceanography Marine biology Hydrology Ecosystems research Geology
