Tes-1358a Sound Analyzer Real Time 1/1 & 1/3 Octave Band Analysis Tes1358a

US $2,500.00

HONGKONG, China
Feb 15th

Open on mobile:
QR code

Features: TES-1358A (230V) TES-1358B (110V) Real-time 1/1-Octave and 1/3-Octave analysis. Wide linearity range of 100dB. Large display with backlighting. Real time clock with calendar. Memory max. 10000 records of Lp data. RS-232 interface Specifications: Applicable standards IEC 60651 Type2, IEC 60804 Type2, BS EN 6065, 1994, IEC 1260-1995 Microphone 1/2-inch Electrect condenser microphone Accuracy +/- 1.5dB (ref 94dB @ 1KHz) Measurement range 30dB to 130dB Measurement function Lp , Leq , LE , Lmax , Lmin Frequency range 25Hz ~ 10KHz Frequency weighting A ,C, Flat Time weighting Fast , Slow Display 160*160 dot matrix display with back light Sound level meter display Numerical : 4 digits, up data cycle 0.5s, resolution 0.1dB Bar graph : Scale range 100dB , update cycle 0.125s Real time clock : Year, Month, Day, Hour, Minute, Second 1/1- 1/3 Analyzer level range 5 ranges in 10-dB step, 20-90dB/ 30-100dB/ 40-110dB/ 50-120dB/ 60-130dB 1/1 Octave and 1/3 Octave band filters 1/1 Octave band center frequencies : (9 bands) 31.5Hz, 63Hz, 125Hz, 250Hz, 500Hz, 1KHz, 2KHz, 4KHz, and 8KHz. 1/3 Octave band center frequencies : (27 bands) 25Hz, 31.5Hz, 40Hz, 50Hz, 63Hz, 80Hz, 100Hz, 125Hz, 160Hz, 200Hz, 250Hz, 315Hz, 400Hz, 500Hz, 630Hz, 800Hz, 1KHz, 1.25KHz, 1.6KHz, 2KHz, 2.5KHz, 3.15KHz, 4KHz, 5KHz, 6.3KHz, 8KHz 10KHz. Extension cable Available in lengths of 5m (TL-F47/5M) and 10m(TL-F47/10M) Memory capacity 10000 data (Sound level meter mode) Signal output AC output : 2 Vrms (at full scale) DC output : 10mVDC / dB Serial interface : RS-232 , 9 pin D-sub Power 4 pcs of C size 1.5V (LR14) batteries External DC power supply 6V, 1A Battery life Approx. 2hrs Operating Temperature/Humidity 0 °C to 40 °C , 10 to 80% RH Dimensions & Weight 34.5(H)*10(W)*6(D) cm & Approx. 950g (including batteries) Accessories Instruction manual, Battery x 4, Carry case, Software, RS232 cable, 9 Pin to 25 Pin gender changer, Adjustment screwdriver, wind shield, 3.5f plug, AC/DC Adaptor.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	TES
Model	TES-1358A
