Store home Accessaries Basic Instrument Calibration Kit Data/Telecom Logic Analyzer Network Analyzer Network Hardware Optical Measurement Oscilloscope Power Supply RF Communication Singal Generator Spectrum Analyzer Other Tescom TC-3000A Bluetooth Test Set Description TESCOM TC-3000A Bluetooth Tester eliminates the need for several costly testers by combining key RF and Protocol test & measurement functions in one convenient box. Designed for a wide range of applications in R&D, manufacturing, QA and service, this feature-packed powerful instrument is simple to use, lightweight and portable, and may be operated with all standard AC voltages. In addition to Bluetooth testing applications, TC-3000A may be used for non-Bluetooth RF testing along the 2.4GHz ISM band. System Architecture: TC-3000A is made up of two main blocks, a RF/DSP module and a host CPU module, and is connected by a host controller interface (HCI) that is identical to Bluetooth system architecture. The RF/DSP module provides an RF interface to DUT, performs physical measurements and manages the Bluetooth link. The internal host CPU (PC), which runs on a Linux platform, takes care of user interface (UI) functions including display, key input and I/O controls for RS-232C, USB, PCMCIA, LAN and other standard peripheral devices. The adoption of an open OS minimizes unnecessary constraints on system optimization. This simple, elegant system architecture takes advantage of both the power of DSP and the convenience of a PC. Custom Protocol Stack: The TC-3000A Bluetooth protocol stack has been developed with in-house technology in order to gain total control of the performance and feature set of the tester. Its unique protocol stack architecture positions ?®queues?? between protocol layers, making it conceptually simple and easy to apply. This approach helps guarantee the system??s long-term supportability, while efficiently handling future customization and enhancement requirements. Versatility of TC-3000A: TC-3000A can interface with DUT through most known HCI interfaces. Additionally, the RF/DSP module can relinquish control to an external PC through standard HCI, allowing for an emulated Bluetooth development environment. Remote connection through TCP/IP allows the efficient control of multiple testers from a PC located practically anywhere in the world. Speed test mode: It is essential to minimize the test time in manufacturing. TC-3000A is capable of skipping the time-consuming INQUIRY procedure by reading the Bluetooth device (BD) address directly through HCI. Test configurations can be edited to reduce the number and time of tests. Key Features Bluetooth V1.1 Specification Compliant RF and Protocol Combination Tester Bluetooth RF and Baseband Measurement Functions - Basic spectrum analyzer - Modulation waveform - Power versus time - Power versus channel - Bit Error Rate (BER) - Utility digital signal generator - User definable Baseband IN/OUT ports for real time signal monitoring and external modulation Basic Bluetooth Protocol Analyzer Functions - Supports Master and Slave modes - Link test in Pico-net - Packet information in Baseband, LMP, and HCI layers - Direct HCI command execution from the screen Bluetooth Conformance Test - Test Cases defined in Bluetooth Test Specifications - 15 RF test cases supported including dirty transmitter and spectrum (3 RF test cases require additional equipment) - 13 basic Baseband test cases - LMP, Local HCI, and Remote HCI - User definable test parameters and limits - Batch mode or single mode Supports Audio (SCO Link) Functional Testing Device HCI Interface Options: USB, RS-232C and PCMCIA Remote Opey RF isolated condition with reliable RF coupling. A simple isolation box that disregards internal resonance and shielding qualification will result in unreliable RF test data. All TESCOM isolation boxes are designed to minimize this problem. In practice, OTA coupling over a wide frequency band exhibits some level of frequency slope due to antenna bandwidth or cable connector reflections. This channel-dependent residual slope may need calibration to guarantee the accuracy of TX power measurement. Key Specifications Reliable High RF shielding up to 2.5GHz due to simple up-down lid motion. Pneumatic control of lid and optional automatic test fixture motions EMI filters on all data ports and power line Manual or remote operation (RS-232C) Modular I/O design for possible customization of data and RF connection Safety shield protective cover Fixture control air outputs for custom test fixture Red and Green LED's for Pass/Fail indication Dual pressure control and Lid Down Sensor for safety CE compliant : EN 292-1:1991, EN 292-2:1991/A1: 1995, EN 983 : 1996, EN 1050:1996, EN 60204-1:1997 Installed Option : None Terms and Condition 1. Shipping : Worldwide 2. Incoterms : EXWORKS (SEOUL KOREA) 3. Payment : Cash In Advance 4. Warranty : 1 month About Nubicom NUBICOM is the largest independent supplier in Korea for buying, selling, renting and leasing of new, used, and refurbished test & measurement and network/server/storage equipment. A commitment to product selection, competitive prices and dedicated customer service distinguishes NUBICOM. For 10 years, NUBICOM has been exceeding expectations for T&M and NW/Server/Storage engineers in R&D, manufacturing and field applications. We offer expertise in the markets of education, aerospace and defense, wireless, wireline, component, semiconductors/computers, automotive, consumer electronics, etc. More than 5,000 instruments available, NUBICOM offers equipment for a variety of applications. We supply a wide range of quality equipment such as router, switch, oscilloscopes, spectrum analyzers, signal generators, network analyzer, component tester, RF communication tester, logic analyzer, WLAN/bluetooth/GPS Tester, VQT/DECT, OPTIC and basic test instruments from worldwide leading companies. Nubicom’s business lines are branched out by 2 categories: Test & Measurement and IT solution. Test & Measurement Business: Used equipment selling & rental : All products from well-known T&M makers such as Agilent, R&S, Anritsu, Litepoint and Advantest, etc. Nubicom is the largest provider for used T&M equipment in S.Korea. Repair and maintenance service : All products from worldwide well-known T&M makers. New equipment selling: Brand new products from Tektronix, Aeroflex, Keithley, Wilder-technologies and Redwoodcomm. Nubicom is the authorized sales distributor for these companies. Website : IT Solution Business: Used equipment selling : All products from well-known network hardware makers such as Cisco, Juniper, Extreme, Force10, IBM and HP, etc. Network hardware products rental : All products from worldwide well-known network hardware makers. Nubicom provides in full range of network hardware equipment including Routers, Switches, Servers, VoIP products, Memory, Modules and Accessories. Website : Nubicom buy and sell electronic test & measurement equipment and network hardware equipment worldwide to industry leading corporations, smaller end users, and government agencies. In addition, we provide a wide range of technical, logistical, and financial services and solutions that covers the entire life cycle of customer’s equipment. Nubicom is headquartered in Seoul, South Korea. Warranty Info New Equipment We are following the manufacturer’s own warranty. Basically it is starting from 1 year to 5 years Customer can choose the warranty options. Used Equipment We support 14 days ROR (Right of Refusal) and basically 1 month warranty for reseller. Customer can return the purchased equipment to Nubicom within 4 days and will get the refund quickly. And also we do free repair service if the equipment is electrically defected within 1 month after delivery. Extended Warranty We propose any extended warranty contract to any customer with additional cost. Payment Info When customers purchase any equipment from Nubicom, customer has to pay in advance if customer doesn’t get any pre-agreement about credit in payment. Shipping Info We are supporting any global forwarders such as FedEX, DHL and UPS. Customer has to pick up the equipment from Nubicom's warehouse directly. with additional cost, we can support other terms, EXW or DAP Contact Us Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
