Test Load / Dummy Load / Selectable To 3a / Diy Kit / Led Or Laser Drivers!!!

US $15.00

  • Banning, California, United States
  • Jan 29th
Open on mobile:
QR code
These test loads have jumper terminals to select the number or diodes, 1-10, you want to use or simulate a specific voltage drop. Now, for some people who are wondering what is a test load/dummy load and why do we need it? A test load or dummy load acts like or simulates a laser diode to safely measure how much current is going through it from the driver. Without one you run the risk of destroying or damaging the laser diode. NOTE #1: These diodes are safely rated up to 3A, but at higher currents (more than 1A) they will get hot. I would advise less than 1 minute cycles for high currents or if you want you could place a small heat sink on top of these diodes and or resistor to help cool the test load if you plan on using these for more than 1 minute. Easy to find small heat sinks at Radio Shack, DX, or you can source your own. NOTE #2: If the driver you are using has a capacitor (most likely), you need to discharge the capacitor using a resistor before connecting it to the actual laser diode to prevent voltage spikes that might kill it or damage it. They compose of: - (1) Custom test load PCB - (10) 1N5404 diodes (rated up to 3A) - (18) male straight gold plated breakaway headers (rated up to 3A) - (1) jumper connector - (1) metal oxide 1 Ohm 5 Watt 2% tolerance resistor 10 diodes for a selectable range (number designates diodes on the jumper) *remove jumper pin to use all 10 diodes* What you will get in the package: (1) x test load kit (1) x instruction paper (how to assemble/how to use)
