Texas Instruments Bldc Motor Driver Board -- Perfect For Diy Ebike Controller!

US $190

  • Reno, Nevada, United States
  • Jun 9th
Open on mobile:
QR code
You are bidding on a reference design board for a TI Stellaris LM3S8971 micro controller.  This board includes drive electronics and an analog input making it perfect for driving an electric bike.  As programmed the board will work great for this application, or you can re-program for your use.  TI furnishes an IDE for these boards. Below are the specifications of this board.   Overview The MDL-BLDC control board provides the following features: Controls three-phase BLDC motors up to 36 V 500 W 10/100 Ethernet and CAN interfaces Four-quadrant operation Hall Effect, Quadrature, and Sensorless operation modes Extensive configuration options using Windows graphical user interface (GUI) Easy to customize—full source code and design files available General Features On-board braking circuit Incremental quadrature encoder input Analog and digital control inputs Test mode push-button Status LEDs indicate Power, Run, and Fault conditions Optional power-managed fan for forced-air cooling Screw terminals for all power and signal wiring Communications Features  10/100 Ethernet –  Auto MDI/MDIX –  Traffic and link indicator LEDs –  MCC protocol supports multiple boards on the same network  CAN bus –  Support up to 1 Mbps –  On-board selectable CAN terminator  Serial port –  Header provides TXD and RXD signals –  CMOS signal levels –  MCC communication protocol –  115.2 kbaud, 8 bit, no parity, 1 stop bit
