Texsteam 4327

US $317,499.00

houstan, Texas, United States
Aug 25th

Open on mobile:
QR code

Series 4300 Electric Drive Chemical Injector, Plunger Size: 1", Injector Heads: Single Head, Gear Ratio 100:1 Series Description: The Series 4300 Chemical Injectors are electric motor driven, positive displacement pumps utilizing an integral worm gear drive available in three different standard ratios and 6 plunger sizes to provide a wide selection of volumes and pressures .063 GPD up to 325 GPD per head, against pressures from 150 to 5000 psig. An optional 10 to 1 gear reducer, mounted externally, is available for extra low pumping rates from 1-1/4 gallons per day down to 1/2 pint per day. Features: - Integral gear drive and crosshead mechanism in heavy cast iron housing with an oil level sight gauge. - Output gear of high strength alloy iron is supported in a sturdy special bearing arrangement for maximum rigidity to assure extremely long fife. - A special drip-ring feature on the plunger prevents chemical from being conducted into the gear box and contaminating the lubricant. - Oil level gauge on gear box. - A full gasket under the gear box cover provides a positive barrier against moisture, dirt, and corrosive vapors. - Choice of liquid ends ...all interchangeable. - Multiplex models with up to 8 heads driven by a common motor are available. - Stainless steel tanks - Flow rate is adjustable while the pump is running.
