Tft Digital Oscilloscope Kit Power Adapter Clip Cable Probe Assembled Machine

US $85.99

Loudi, Hunan, China
Jul 31st

Open on mobile:
QR code

TFT Digital Oscilloscope Kit Power Adapter Clip Cable Probe Assembled Machine Features: Adopts ARM Cortex-M3 processor (STM32F103C8), and includes a 2.4-inch color TFT display screen Used for secondary development on the basis of this kit, for example, it can be changed to millivoltmeter, data loggers. Come with instructions, easy to install and operate. Auto/normal/single trigger modes, easy to capture the moment waveform. Available rising or falling edge trigger. Observable previous waveform before trigger (negative delay). Can freeze waveform display at any time (HOLD function). Waveform parameter digital display, including frequency, period, pulse width, duty ratio, MAX./MIN./AVG./Peak-Peak/virtual values. Waveform storage function: Will not lose the waveform after powering off. Short-circuit and open-circuit detection: Can help the user find out the soldering error. TFT controller recognition function. The SMD has been soldered, more suitable for electronic beginners. Specifications: Type: Finished Product Model: US/ EU (optional) Number of Channel: 1 Analog Bandwidth: 0-200KHz Sensitivity Range: 5mV/Div - 20V/Div Sensitivity error: < 5% Maximum Input Voltage: 50Vpk (1X probe) Input Impedance: 1M ohms/20pF Resolution: 12 bits Record Length: 1024 points Coupling Modes: DC / AC / GND Maximum Real-time Sampling Rate: 1MSa/s Time Base Range: 10us/Div - 500s/Div Trigger Modes: Auto, Normal, and Single Trigger Types: Rising/falling edge Trigger Position: Center of Buffer Display: 2.4" Color TFT LCD with 320*240 Resolution Supply Voltage: DC 9V(8-10V Acceptable) Current Consumption: ~120mA @ 9V Product Size: 115 * 75 * 22mm / 4.53 * 2.95 * 0.87in Product Weight: 92g / 3.24oz Package Size: 202*110*38mm/7.95*4.33*1.50in Package Weight: 314g/11.07oz Note: Due to the light and screen difference, the item's color may be slightly different from the pictures. Please allow 1-3cm differences due to manual measurement. Package: 1 * Oscilloscope 1 * BNC-clip cable 1 * Probe 1 * Power adapter 1 * Users Manual For any question please contact us

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Number of Channels	2
Record Length	1024 points
Model	DS0150
Sensitivity Range	5mV/Div - 20V/Div
Modified Item	No
MPN	0648960965
Country/Region of Manufacture	China
Analog Bandwidth	0-200KHz
Custom Bundle	No
Digital Channels	1
Oscilloscope Type	Digital Oscilloscope
Display resolution	320*240 Pixels
Brand	Unbranded
DIY Supplies	ELECTRICAL
Maximum Bandwidth	100 MHz
Input Impedance	1M ohms/20pF
