Th2617 Precision Capacitance Meter 100hz-100khz Frequency 0.05% Basic Accuracy

US $1,140.00

???, ???, China
Jun 9th

Open on mobile:
QR code

Introduction ?TH2617 capacitance meter is a capacitance parameter measurement instrument with high accuracy, wide measurement range. It provides 6 typical measurement frequencies: 100Hz, 120Hz, 1kHz, 10kHz, 40kHz, 100kHz, and 3 measurement signal levels: 0.1V, 0.3V, 1.0V. With the unique double-frequency measurement function, TH2617A can measure at two randomly-set frequencies, output and display results, and sort. The meter can be used for high-speed measurement on production line and high-accuracy measurement in lab. HANDLER and RS232C interfaces help build an automatic component sorting system and communicate with computer. And measurement conditions can be sent to printer through printer interface. Features ? 6 selectable typical measurement frequencies, up to 100kHz ? Ideal instrument to perform high-accuracy capacitance measurement ? Measurement speed up to 20times/second ? Direct, absolute deviation, relative deviation ? Measurement state setup and parameter storage function ? Unique double-frequency measurement function (TH2617A) ? Sorting alarm volume control and alarm state selection ? Set parameter protection function ? 4-bin sorting and HANDLER interface Specifications Measurement function Measurement parameters Cs-D, Cp-D, ESR-D, EPR- D Basic accuracy 0.05% Equivalent circuit Series connection, Parallel connection Mathematical function Absolute value deviation, ?% Range mode Auto, Hold Trigger mode Internal, Manual, External Measurement speed Fast: 20, Medium: 5.1, Slow: 1.5 (times/second) Average times 1 - 99 Calibration function Open/Short sweep correction Measurement terminal 5-terminal Display mode Direct, ?, ?%, V/I (V/I monitor) Display Double 5-digit LED display Measurement signal Signal frequency 100Hz,120Hz,1kHz,10kHz,40kHz,100kHz Output impedance Dependent on range Test level 0.1Vrms, 0.3Vrms, 1Vrms Measurement display range R 0.0001? - 99.999M? C 0.0001pF - 99999? F D 0.0001 - 99999 ?% 0.00% - 9999% Comparator and interface Comparator 4-bin sorting, alarm volume control, alarm state selection Interface RS232C, Handler, Printer General Specifications Operating temperature & humidity 0°C-40°C, ?90%RH Power supply Voltage 198V-242V Frequency 47.5Hz-63Hz Power consumption

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	TH
MPN	TH2617
Model	TH2617
