Th2816b Precision Digital Lcr Meter Basic Accuracy 0.1% 50hz-200khz Frequency

US $1,525.00

???, ???, China
Jun 9th

Open on mobile:
QR code

Introduction TH2816B is a new precision LCR meter combined with years of technical experience and newest measurement technology of instrument industry. With powerful measurement functions, high performance and low cost, TH2816B have been one of the world advanced instruments, and it provides users a super value measurement resolution and experience. The meter offers stable 6 digit resolution, wide frequency range (50Hz to 200kHz), programmable signal level (0.01V to 2.0V), up to 30 meas/sec measurement rate, 9 measurement ranges, 30? or 100? constant output impedance and friendly operation interface. TH2816B can be used for incoming inspection of components, quality control of product line and high accuracy laboratory use. The optional HANDLER, GPIB, RS232C interfaces make it easy to build an automatic component test system, communicate with the computer and record the test results. Features ? 240x64 dot-matrix graphics LCD display ? Friendly user's interface and easy operation ? TH2816B: 37 typical frequency points, 50-200kHz ? Programmable single-voltage level from 10mVrms to 2.0Vrms ? World-level stability and accuracy ? 6 digit readout resolution ? Up to 30meas/sec Measurement rate ? Precision LOAD correction function ? Selectable signal source output impedances: 30?, 100? ? Direct control function for TH1773/TH1775 DC bias source ? List sweep function for up to 4 frequencies, signal levels and DC bias levels ? Direct, ? ABS and ?% display modes ? 12 control setting files memory ? Built-in comparator, 10 Bins and bin counters (TH2816A/B) ? Test signal level monitor function ? Key lock function ? Optional Handler interface ? RS-232C and optional GPIB interfaces Specifications Measurement function Test parameter |Z|, C, L, X, B, R, G, D, Q, ? Basic accuracy 0.1% Equivalent circuit Series connection, Parallel connection Math function Deviation and Percent Deviation Ranging mode Auto, Hold Trigger mode Internal, Manual, External and Bus Measuring rate Slow: 650ms/meas Med: 90ms/meas Fast: 32ms/meas Correction function Open, Short and Load Measurement terminal 5-terminal Averaging rate Delay time 0—60sec,with step of 1ms List sweep List sweep for up to 4 frequencies, signal levels and DC bias levels Display mode Direct, ?ABS, ?%, V/I( V/I monitor), Bin number and bin counter Display 240x64 dot-matrix LCD display, 6-digit resolution Test signal Signal frequency Over 10,000 frequencies from 50Hz to 200kHz Output impedance 30? , 100? Test level 10mVrms—2.0Vrms, 10mV step Measurement display range |Z|, R,X 0.00001? — 99.9999M? C 0.00001pF — 999.999mF L 0.00001?H — 9.99999kH G,B 0.00001?S — 999.999S D 0.00001 — 9.99999 Q 0.00001 — 99999.9 ?(DEG) -179.999? — 179.999? ?(RAD) -3.14159 — 3.14159 ?% -999.999% — 999.999% Comparator, memory & interface Comparator 10 Bins: BIN1 to BIN3 , OUT of bins, and additional AUX bin Memory 12 control settings memory for store/recall Interface RS-232C, HANDLER, GPIB (Optional)
