Th2817a 0.05% 50hz-100khz Frequency Precision Digital Lcr Meter Basic Accuracy

US $1,698.00

China, China
Jul 8th

Open on mobile:
QR code

Ashley Automation TH2817A 0.05% 50Hz-100kHz Frequency Precision Digital LCR Meter Basic Accuracy Introduction TH2817A is a new precision LCR meter combined with years of technical experience and newest measurement technology of instrument industry. With powerful measurement functions, high performance and low cost, TH2817A has been one of the world advanced instruments, and it providesnbsp;users a super value measurement resolution and experience. The meter offers stable 6-digit resolution, wide frequency range (50Hz to 100kHz for TH2817A), programmable signal level (0.01V to 2.0V), measurement rate up to 30times/second, 9 measurement ranges, 30 or 100 constant output impedance and friendly operation interface. They can be used for incoming inspection of components, quality control of product line and high accuracy laboratory use. The HANDLER, GPIB, RS232C interfaces help build an automatic component test system, communicate with the computer and record the test results. Applications Passive components: Evaluation of Impedance Parameters for Capacitors, Inductors, Cores, Resistors, piezoelectric devices, Transformers, Chip Components, and Network Components Other components: Impedance evaluation of printed circuit boards, relays, switches, cables, batteries, etc. Please allow 3 - 4 weeks lead time for this new product to arrive. This item comes with a one warranty from the manufacturer. TH2817A is a new precision LCR meter combined with years of technical experience and newest measurement technology of instrument industry. With powerful measurement functions, high performance and low cost, TH2817A has been one of the world advanced instruments, and it provides users a super value measurement resolution and experience. The meter offers stable 6 digit resolution, wide frequency range (50Hz to 100kHz for TH2817A ), programmable signal level (0.01V to 2.0V), up to 30 meas/sec measurement rate, 9 measurement ranges, 30 or 100 constant output impedance and friendly operation interface. TH2817A can be used for incoming inspection of components, quality control of product line and high accuracy laboratory use. The HANDLER, GPIB, RS232C interfaces make it easy to build an automatic component test system. Features 24064 dot-matrix graphics LCD display Friendly user's interface and easy operation TH2816A: Over 12,000 frequency points available from 50Hz to 200kHz TH2816B: 37 typical frequency points TH2817A: 16 typical frequency points available from 50Hz to 100kHz Programmable single-voltage level from 10mVrms to 2.0Vrms World-level stability and accuracy 6 digit readout resolution Up to 30meas/sec measurement rate Precision LOAD correction function Selectable signal source output impedances: 30, 100 Direct control functon for TH1773/TH1775 DC bias source List sweep function for up to 4 frequencies, signal levels and DC bias levels Direct, ABS and % display modes 12 control setting files memory Built-in comparator, 10 Bins and bin counters (TH2816A/B) Built-in comparator, 4 Bins and bin counters(TH2817A) Test signal level monitor function Key lock function Handler interface RS-232C and optional GPIB interfaces Specifications Measurement function Test parameter |Z|, C, L, X, B, R, G, D, Q, Basic accuracy 0.05% Equivalent circuit Series connection, Paralel connection Math function Deviation and Percent Deviation Ranging mode Auto, Hold Trigger mode Internal, Manual, External and Bus Measuring rate Slow: 650ms/meas Med: 90ms/meas Fast: 32ms/meas Correction function Open, Short and Load Measurement terminal 5-terminal Averaging rate

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	TH2817A
Brand	Tonghui
MPN	Does Not Apply
UPC	Does not apply
