Thermal Arc Scout Ta-4/170-h Welder Stick Tig

US $2200

Lake Wales, Florida, United States
Jun 22nd

Open on mobile:
QR code

Portable welders depend on the Scout® for quality weld output and consistent auxiliary power. The Scout®, TA-4/170-H, is an engine-driven welding generator with excellent performance for STICK and TIG welding. The heavy-duty design provides 60% Duty Cycle at 170 Amps with 30-170 Amps weld output and delivers the highest available auxiliary power while welding. The heavy-duty rugged roll case design is standard along with HF protection, muffler, low oil pressure shutdown, hour meter, and scratch start TIG. The unique Power-Plus® patented alternator delivers a smooth weld output. Its brushless design increases efficiency – reducing maintenance and extending the life of the machine. Separate windings are used for welding and auxiliary power, offering the highest quality auxiliary power. The generator is powered by a rugged 1-cylinder, gas fuel, air-cooled Honda engine. Honda industrial engines provide high fuel efficiency and performance and are backed by Honda's strong parts and service support. The Scout® is ideal for applications in general construction, structural fabrication, pipe welding, rental operations, professional welding, maintenance vehicles, mobile repair vehicles, in-plant maintenance, mining, railroad maintenance and stand-by power. Part Number Rated Output @ Duty Cycle Output Range Dimensions (H x W x D) Net Weight 11-1002 170 A / 26 V @ 60% 30 - 170 Amps 19” x 29” x 20” 482 x 736 x 508 (mm) 205 lbs. (92 kg) Engine Honda GX200 OHV Type 1-cylinder air-cooled gas HP & Welding Speed 9 HP @ 3,600 RPM Fuel Tank 1.6 gal. / 6 L Oil Capacity 1 qt. / 1.1 L Selection WELDING OUTPUT Process Aux. Pwr. Guide Type Current Range (Amps) STICK TIG Scratch TIG Lift MIG Flux Cored CAG Sub Arc Engine Max kW (AC) ENGINE DRIVEN *For full AC / DC TIG capacity Plug a Pro-Wave Inverter into AUX. PWR Outlet MPM165 (Burco® Brand) CC DC 40-150 X X G 2 (DC) Scout® TA-4/170-H CC DC 10-170 X X G 4 PROCESS STICK SCRATCH TIG •60% Duty Cycle @ 170 Amps • Gas Engine - 9 HP Honda - Efficient and Reliable - OHV Series •Auxiliary Power - Highest Available While Welding SUGGESTED WIRE FEEDERS Hefty® II CC/CV, Hefty® II Stainless, Heavy Duty CC/CV Running Gear, STICK Kit, TIG Kit SEE ACCESSORIES PAGES For Details & Ordering Information ACCESSORIES FEATURES Scout® TA-4/170-H $1,925.00 Part Number Rated Output @ Duty Cycle Output Range Dimensions (H x W x D) Net Weight 11-1002 170 A / 26 V @ 60% 30 - 170 Amps 19” x 29” x 20” 482 x 736 x 508 (mm) 205 lbs. (92 kg) ENGINE DRIVEN DC STICK w/Limited TIG (No Foot Control Capacity) Additional Accessories are respectively shown on other pages in this "Joining & Cutting With Electricity" Section Uses 50mm International (DINSE) Style Welding Cable Plugs 115V, 60 Hz, 1 Phase 2kVA 4kVA230V, 60 Hz, 1 Phase •115 VAC / 230 VAC •Single Phase •Outstanding Low End Performance - Excellent E6010 Electrode Opera
