Thermo 780nm Single Mode External Cavity Diode Laser Ecdl 50mw

US $1,750.00

  • Minneapolis, Minnesota, United States
  • Mar 11th
Open on mobile:
QR code
Thermo 780nm Single Mode External Cavity Diode Laser ECDL The Thermo ECDL laser is a temperature controlled external cavity diode laser.  These lasers are from Thermo Raman Spectrometers.  They are configured in the Littrow cavity configuration.  The grating used is gold plated, UV blazed at 1800 lines per mm.  The collimator is a Thorlabs C230TME-B.  The laser diode is temperature controlled with a small peltier ‘TEC’ element and a 10K thermister. This is THERMO part number: 470-226800  780nm NIC Laser Assembly The laser controller board allows for adjustment and monitoring of laser diode current and laser diode temperature.  Please see picture for those pinouts. This laser requires a dual 12v and 5v power supply to operate.  2 amps current should be sufficient. After power is applied, the leftmost led (CR1) will illuminate green.  This indicates the laser has been turned on and the Thermoelectic TEC cooling system is active. The middle LED (CR2) turns on next.  Finally, once the TEC temperature has stabilized, the right most led (CR3) will illuminate indicating power has been applied to the laser diode. The grating can be adjusted to shift the output wavelength.  I measured the wavelength of this particular laser using an Ocean Optics USB2000 spectrometer.  It's wavelength was 771nm. Output power has been measured at 52mW.  Output power can be adjusted by the LD current set potentiometer.  Also, inside the laser head is a small turning mirror.  Replacement of this mirror may increase output power as for some reason the coatings look tarnished.  Replacement of this mirror does not effect alignment of the Littman Cavity.  It is only used to direct the beam out of the cavity. I also have optics for sale that were used with these lasers.  Please see one of the pictures that show how they were used.  There is a holographic notch filter, and 2 waveplates.  I am not sure if the waveplates are quarter wave or half waveplates.  These waveplates have rotating mounts to adjust the polarization. Please ask if you have any questions, or would more pictures. I have 4 available.  Buy 2 and I will include a power supply. PLEASE NOTE: Laser Power Meter and Optics set are not included in this auction.  Thanks for looking!  Free Shipping in the USA! T
