Thermo Electron/westronics Svm Paperless Chart Recorder

US $999.99

Phoenix, Arizona, United States
Jan 30th

Open on mobile:
QR code

Thermo Electron / Westronics SmartView SVM Paperless Chart Recorder (3-Channel) Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Thermo/Westronics and may vary slightly due to upgrades, options, or revisions this unit may or may not have. Unit powers up and seems to work. We have no way to test it after that. This unit has been directly replaced by the model SVC-100. This unit is very similar but it is a Monochrome display. There are a lot of specifications in here that may not apply to this current unit because of the options that these things can have. For instance, the SVC is a color display but this is a monochrome display. List Price: Was around $2,200.00 to $4,000 The Unit's Serial Tag Reads: Serial Number: SVM8002 Manufacture Date: 4-97 The Configuration Tag Reads: Calibrated At: 60 Hz Input Upper: 3 Channel Input Lower: None Tx Supply: None Buffer: Standard Digital I/O: None Communication: RS-232 Input Power: AC Part Number: SVM-300-10-11-001 Link to the Manual: Appendices Chapter 1 Chapter 2 Chapter 3 Chapter 4 Chapter 5 Chapter 6 Chapter 7 Chapter 8 SmartView SVC/SVM Videographic Recorder: The SMARTVIEW Videographic Recorder is actually a miniature data acquistion system. The SVC displays data with exceptional calrity on an active matrix color LCD display with touchscreen control. Display modes include: trend, bargraph, and digial. Data can be compressed in time and scale or searched for by time/date and alarm conditions. Real time information can be viewed while simultaneously storing historical data on either a PC card or 3.5" floppy disk. Historical data can be read on the SmartView direclty or on a PC from a PC or floppy disk, or exported to a PC for use in spreadsheets, database or analytical software packages via an addressable RS485 or RS232 serial port. This recorder will meaure and process up to twleve channers. These channels include up to six directy inputs consisting of linear, square root, and logarithmic voltage and currnet inputs, and a wide variety of RTDs and thermocouples, plus up to six addtional external, conditional or calculated points. Key Features: Paperless - no paper rolls to thread or store Compact 144 mm x 144 mm DIN size High resolution active matrix color LCD display (SVC), the SVM is a monochrome display Touchscreen configuration Trend, bargraph, and digital display modes Up to six direct inputs, twelve total points Standard math package with on-board capabilities to do math calculations Internal RAM data storage (up to 640 Kb) and PC card or 3.5" floppy disk data storage Set up and automatically search data files for signal values, alarms or date/time parameters RS485 multi-drop or RS232 bi-directional isolated communication port (this unit is setup for RS-232) Selectable MODBUS™ or ASCII communication 48 alarm setpoints (high, low or rate) Windows™-based companion software (not included) CE Certified Specifications: Number of Channels: Up to 12 total channels - fully functional (this unit has 3 channels) Input Signal: Universal DC Voltage range ± 50 mV to ± 10 VDC Universal DC Currents ± 2 mA, 4-20 mA, 10-50 mA Thermocouple: J, K, T, E, R, S, B, C, N RTD: 5 pole switching. 100, 500 ohm Pt 385, 100 ohm Pt 392 (special module for 10 ohm RTDs) - I don't believe this unit has the RTD option) DC inputs via screw terminal connectors Input Accuracy: Voltage: ±0.05% Current: ±0.1% including factory supplied shunt resistance Thermocouple: ±1° for J, K, T, E, Nicrosil-Nisil, and Nickel-Nickel Moly; ±3° for R, S, and C; ±4°for B RTD: ±0.5° Memory: Memory cards available: 128K, 256K, 512K, 1.024M, up to 4M Display : Monochrome Alarms: 48 total, 4 per channel including high, low or rate of change Power: 117 VAC/230 VAC, 50/60 Hz 24 VDC, 125 mA isolated loop power supply 300 VDC or AC peak isolation Operating Temperature: 32°F to 120°F, (0°C to 50°C), 32°F to 104°F, (0°C to 40°C) with floppy For More Pictures Please Click the Following: Picture 2 - Front View Picture 3 - Back View Picture 4 - Display, Up-close Picture 5 - Floppy Drive Picture 6 - Configuration Tag Picture 7 - Serial Number Tag $15.00 minimum for packaging, handling, and order processing. Shipping to be determined by destination. If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 02/28/08 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Oct-31-13 at 21:10:16 PDT, seller added the following information: Click Here. Double your traffic. Get Vendio Gallery - Now FREE!

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Thermo Electron / Westronics
MPN	SVM
Model	SmartView SVM
Country of Manufacture	United States
