Thermo Gastech Safe-t-net 2000 Gas Monitor / Two Channel Controller Card

US $1100

Gainesville, Florida, United States
Oct 30th

Open on mobile:
QR code

Excellent used condition - Few signs of use - Guaranteed to arrive in good working order. Some specifications: • Preset Ranges - Configurable, with indicator for % LEL, ppm, or % volume • Detector Heads - Combustible, oxygen & toxic • Inputs - Two 24 Vdc, 4 to 20 mA analog inputs; source type - 2 or 3 wires • Analog Output - 4 to 20 mA source for each channel (1,000 ohmsmaximum) • Relay output - Individual, low (Form C), high (Form A or B) for each channel / programmable for latching/non-latching, energized/de-energized • Common fault (Form A or B): normally energized, programmable for latching/non-latching / Each relay rated at 10A/12 VAC • Operational Temperature -4°F to 113°F (-20°C to 45°C) • Humidity 0-95% RH, non-condensing • Area Classification - General purpose • Low/High Alarms - Independently adjustable from "off" to full audible/visual indication - Can be acknowledged and activated for rising/falling levels • Calibration Time Out - Programmable up to 99 seconds (disablement available) • Alarm Delay - Programmable up to 99 seconds (disablement available) • Operating Voltage - 18 to 30 Vdc, 24Vdc normal • Power Requirements - 0.25A maximum fused at 1.0A • Control Card Dimensions: 1.6 " (41mm) L x 11.35" (288mm) W x 6.8" (173mm) H • Weight - 1.3lbs (0.6kg) Will be packaged carefully and shipped via USPS or FedEx - Free shipping to continental USA!
