Thin 1" X 1.080" Controlled Porosity Alumina Ceramic Substrate Sheet No.: 513

US $60

Baldwinsville, New York, United States
Jun 5th

Open on mobile:
QR code

THIN CONTROLLED PORSITY ALUMINA CERAMIC SHEET SUBSTRATE COVER LID SETTER No.: 513 You are buying on a ONE (1) only Thin Square Controlled Porosity Alumina Ceramic Sheet Membrane Substrate Cover Lid Setter. It is in excellent being NOS (New Old Stock). They are made from 99.7% purity Aluminum Oxide (Al2O3) which of course is Alumina. Generally the balance of composition for this purity Alumina material is of Silicon Dioxide (SiO2) which is Silica. This material has very high stiffness, very good corrosion resistance to chemicals at high temperature, and very high refractoriness or use temperature. AMPS- 42520 is a porous, fired alumina ceramic plate used to cover green ceramic parts during firing. The weight of the porous plate enhances the flatness of fired parts while retaining gas permeability during organic removal, thus allowing single firing. The plate may also be used as a setter to promote more uniform burnout of binders during firing. Uses include Fuel Cell applications such as SOFC electrolyte substrates, and other processing of ceramic tape. ESL cover plates are available in several standard sizes as shown below, and in customer-specific configurations. They may be used for a variety of electrical, mechanical, and thermal applications. They are great for firing sample in a high temperature kiln. The may be slumped at 3100 F (1700 C).They are sufficiently thin to use as diffusers of light. They are great for diffusion experiments or sculptural works of art. Your imagination is the only limiting factor in the spectrum of possible applications for this component. Be sure to view all photos as they are an integral component of the item description. The specifications for these components are as follows: Length: Approximately 1.080”+/- 0.020" (~26.8 mm) Width: Approximately 1.000” +/-0.005" (25.4 mm) Thickness: Approximately 0.040” (1.0 mm) Thickness Tolerance: mean ± 10% Camber: (parallel plate gauge) 0.5 mm/100 mm Please Note: There are slight differences in any or all of the dimensions. These are not precision technical ceramic components. Specific Gravity or Density: 3.9 g/cm3 Water Absorption or Porosity: 45.5% Fusion Temperature or Melting Temperature: 2000 °C or 3550 °F Recommended Use Temperature: up to 1450°C Maximum Working Temperature: 1550 °C or 2830 °F Re-Flatting Temperature 1550°C Thermal Conductivity: .25 W/m* K Specific Heat: 0.9 J/g*K Expansion Coefficient or CTE: 7.5 x 10-6 inches/°C Electrical Resistivity at 20 C: 1014 Ohm*cm Electrical resistance at 600 C: 108 Ohm*cm Modulus of Elasticity: 44 x 106 p.s.i. or 350 GPa. These components were not specifically manufactured for an individual application; therefore be sure to check the dimensional descriptions carefully for your application. Future returns or requests for refunds, because of some "fit" issue or the like will not be honored. Please check the other Alumina component variants that are available in my listings for the model or models that best fits your requirement. Your imagination is the only limiting factor in the spectrum of possible applications for these components and materials. If you require additional technical information, design, or application engineering consultation, feel free to contact us. As a materials scientist with four decades experience in high temperature processing, ceramics, dentistry, and jewelry manufacture it will be possible to provide you with creative and imaginative approaches to your requirements. Feel free to ask any questions you may have regarding this item early. Use PayPal only. Combined shipping discount is provided for multiple item purchases. For best results, please be sure to shop using cart, then complete the paying transaction when you are satisfied that all the items you need are in the cart. Items purchased separately will be shipped separately as a unique transaction. Please complete payment transactions within 3 days. Items are generally shipped via USPS first class mail with delivery confirmation. Ask about shipping costs to your country. Feedback is provided for all buyers. We will appreciate yours as well. We strive to maintain excellent customer service; and are able to solve virtually any issues you may have. Every effort to provide the most accurate information about this item and every appropriate precaution in packaging this item is made, to assure that your highest expectations and satisfaction are met, and are exercised to meet this requirement for excellence. In winning this auction or purchasing this item you are agreeing that you will first and must provide the seller every opportunity to provide redress or resolution to any issues you many have concerning this item, prior to lodging a complaint with eBay or leaving any negative feedback about the seller or the item. No.: 513
