Various Thorlabs Optical Test Equipment accessories for use on your breadboard test setups: Qty. 1 KCB05Right-Angle Kinematic Mirror Mount, 16 mm Cage System and SM05 Compatible Retails for $151.20 From Thorlabs: 16 mm Cage Right-Angle Kinematic Mirror Mount Zoom Eight 4-40 Tapped Holes to Mate with 16 mm Cage Systems Mounts ?1/2" (12.7 mm) Optics at a 45° Angle to the Optical Axis Provides ±4? Kinematic Tip and Tilt Adjustment Compatible with SM05-Threaded (0.535"-40) Lens Tubes Post Mountable: One 4-40 Tap and One M3 Tap The KCB05 cube provides kinematic tip and tilt of an optic held in a mounting plate whose mean horizontal position is at a 45? angle. Entrance and exit ports are equipped with an SM05-threaded (0.535"-40) hole. The KCB05 has eight 4-40 tapped holes spaced to mate with our 16 mm cage system standard. SRSCA SR Rod Adapters are necessary to effectively connect, adjust, and lock two of these right angle cage mounts together within the cage system. The kinematic tip and tilt adjustment plate on these cubes is actuated with 100 TPI (Threads Per Inch) adjustment screws that allow for smooth, high-resolution movement. A nylon-tipped setscrew is used to secure ?1/2" (12.7 mm) optics using a 5/64" (2 mm) hex key or balldriver via the mount's rear-loading, double bored hole. The rear loading design does not limit the thickness of the mounted optic and the mounted optic remains accessible even after the mount is fitted with cage rods or lens tubes. The minimum thickness for optics that can be secured by this mount is 0.12" (3 mm). Qty. 1 22mm Diameter Holder. Useful for holding isolators, waveplates, etc. This just the holder from a Thorlabs IO-3D-780-VLP. No optics included. Qty. 3 1/4-20 Thumbscrews All pieces used but in great working condition. Sold AS IS and as shown in the photos. All pieces used but in great working condition. Sold AS IS and as shown in the photos.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Manufacturer	THORLABS
Type	Optical Test Equipment
