Tilting Rotary Table 4"/100mm With 100 Mm 3 Jaw Self Centering Chuck & Backplate

US $246.99

  • Delhi, DELHI, India
  • Jul 26th
TILTING ROTARY TABLE 4"/100mm WITH 100 MM 3 JAW SELF CENTERING CHUCK & BACKPLATE Rotary Table 4" Tilting Hor/vert Rotary Table 4" Tilting. Table height 66 mm in flat position Table graduated 360 degrees in 5 degree divisions 4 Slots Base is 145 mm x 126 mm with two 10 mm mounting holes separated by 110 mm The table tilts upto 90 degrees and can be used anywhere 100MM FRONT LOAD 3 JAW SELF CENTERING CHUCK WITH SET OF REVERSIBLE JAWS(FRONT MOUNT) & BACKPLATE SELF CENTERING 3 JAW LATHE CHUCK 100MM DIAMETER INTERNAL / EXTERNAL JAWS ARE INCLUDED 70MM LOCATING RECESS DISTANCE BETWEEN ADJ CENTRES 72MM 83.14 PCD BOLTS 8MM OVERALL HEIGHT INCLUDING JAWS 65MM MAX SPEED 3500 THIS CHUCK IS FRONT MOUNT WHICH MAKES FITTING A BACK PLATE MORE STRAIGHT FORWARD A QUALITY CHUCK SUPPILED WITH FIXING BACKPLATE FOR ROTARY TABLE & T-NUTS SET
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Setting Position Tilting
Brand Unbranded
MPN Does Not Apply
UPC Does not apply
