TinyG 4 axis CNC controller board + 4 NEMA 17 STEPPER MOTORS, US $165.00 – Picture 0
TinyG 4 axis CNC controller board + 4 NEMA 17 STEPPER MOTORS, US $165.00 – Picture 0

Tinyg 4 Axis Cnc Controller Board + 4 Nema 17 Stepper Motors

US $165.00

  • Mission Viejo, California, United States
  • Jul 4th
Open on mobile:
QR code
DESCRIPTION:    1 PIECE BRAND NEW 4 AXIS CNC CONTROLLER The TinyG project is a high performance, USB based CNC 6-axis controller that supports XYZ linear and ABC rotary axes with 4 motor outputs. It is designed for small CNC applications and other applications that require highly controllable motion control. TinyG is meant to be a complete embedded solution for small or medium motor control. Main Features: Full, integrated motion control system with embedded microcontroller (Atmel ATxmega192) and 4 stepper motor drivers (TI DRV8811) integrated on a ~4 inch square board Four stepper motor drivers Accepts G-code from USB port and interprets it locally on the board Axis/motor mapping to support dual gantry and other configurations (e.g. XYYZ, XYZA, XYZC...) of a 6-axis control (XYZ + ABC rotary axes) setup Acceleration planning performed using constant jerk motion equations (3rd order S curves) for very smooth and fast motion transitions for lines and arcs Very smooth step pulse generation using phase-optimized, smart oversampling, fractional step DDA running at 50 Khz with very low jitter (<<1uSec) Networkable via RS485 to support motion peripherals and for networking mutliple boards for multi-axis systems and for really interesting projects (up to 1000 stepper axes) Stepper drivers handle 2.5 amps per winding which will handle most motors up thru NEMA23 and some NEMA34 motors. Micro-stepping up to 1/8 (optimized DDA makes this smoother than many 1/16 implementations) 4
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Input Voltage 12-30V
Brand Inventables
Model TINYG
Application four Axis
MPN TINYG
Run Method Bipolar
Country/Region of Manufacture Unknown
Number Of Axes: UPC Does not apply
