Tmcm-6110 Six (6) Axis Stepper Motor Controller And Driver 1.1a 24v

US $259.95

Pinckney, Michigan, United States
Feb 17th

Open on mobile:
QR code

6-axis stepper controller/driver 1.1A/24V Product Details Description The TMCM-6110 is an intelligent, compact and ready to use 6 axis motion control solution at low cost for up to six bipolar 2-phase stepper motors. It fully supports the common and easy to use programming language TMCL™, where predefined high level motion control commands like Move to Position or Constant Rotation guarantee convenient and rapid development. Besides user programmable I/O controlled stand alone operation (onboard memory), a variety of high level interfaces allow remote controlled operation. Since all time critical operations, e.g. ramp calculation are performed onboard, the communication traffic is kept very low. Inimitable smooth, precise and fast movements are given by a resolution of up to 256 electrically equidistant microsteps and by the ultimate spreadCycle™ chopper scheme for optimal motor currents. In addition, the TMCM-6110 features the following market revolutionizing technologies: stallGuard2™ can detect and monitor dynamic load changes in high resolution without the need of a sensor. This feature is basic for the automatized load dependent current control coolStep™ for energy and heat efficient motor control and unlimited motor performance. TMCM-6110 Interfaces: CAN, RS485, USB No. Axes: 6 Phase Current, RMS: 1.4A Phase Current, peak: 2A Product State: active RDSon HS: 190m?(2) RDSon LS: 125m?(1) Microstep Resolution: 1...256 Supported Motor Type: Stepper Velocity Ramps: trapezoidal coolStep™ spreadCycle™ stallGuard2™ Motor Supply: 9...28V Length: 100mm Width: 130mm Downloads Datasheet File Size Modified TMCM-6110_hardware_manual.pdf 996.09kB 17-Oct-13 Documentation File Size Modified TMCM-6110_ShortSpec.pdf 600.41kB 17-Oct-13 TMCM-6110_TMCL_firmware_manual.pdf 2.15MB 17-Oct-13 TMCM-6110_hardware_manual.pdf 996.09kB 17-Oct-13 Software File Size Modified TMCM-6110.inf 3.25kB 17-Oct-13 TMCM-6110_V120.hex 162.41kB 17-Oct-13 TMCM-6110_V121.hex 162.41kB 17-Oct-13 TMCM-6110_V124.hex 162.95kB 17-Oct-13

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Trinamic
MPN	10-0200
Model	TMCM-6110-TMCL
Country of Manufacture	Germany
