Toa Sc-610t Paging Loudspeaker Horn Speaker W/ Transformer, New

US $40.00

Manchester, Georgia, United States
Jul 18th

Open on mobile:
QR code

SC-610T The SC-610 is a compact, highly intelligible speaker suited to public address announcement applications. Its external speaker component finished with powder coating, and stainless steel bracket and screws ensure the unit's weatherproof capability. Rated Input10 WLine Voltage70 V line or 25 V lineRated Impedance70 V line: 500 Ω (10 W), 1kΩ (5 W), 2kΩ (2.5 W) 25 V line: 63Ω (10 W), 130 Ω (5 W), 500 Ω (1.3 W), 1 kΩ (0.6 W), 2 kΩ (0.3 W)Sound Pressure Level110 dB (1 W, 1 m at 500 Hz to 2.5 kHz peak level)Frequency Response315 Hz - 12.5 kHzSensitivity when used as Microphone (0 dB=1 mW/10 dynes/c㎡)-24 dB at 1 kHzDust/Water ProtectionIP65PolarityHot: Black, Com: WhiteOperating Temperature-20 %%dC to +55 %%dC (must be free from dew condensation)FinishHorn flare: Aluminum, off-white, powder coating Reflector horn and rear cover: ABS resin, off-white Bracket, screws and bolts: Stainless steel Speaker cable: Polyvinyl chloride insulated cabtyre cable (6 mm in diameter, 600 mm in length)Dimensions222 (W) × 179 (H) × 234 (D) mmWeight1.3 kgOptionSwivel bracket: YS-151S (Can be used instead of the supplied bracket.)Note: Avoid installing the speaker in locations which vibrate considerably, or under environments easy to be oil- TOA SC SERIES PAGING HORN SPEAKERS provide intelligible voice paging and tone signaling for indoor and outdoor sound system applications. Fully weather-resistant for reliable operation in demanding environmental conditions, SC Series models are available with a choice of power ratings from 10W to 50W. High impedance models include SC-610T (10W), SC-615T (15W) and SC-630T (30W), each with a built-in 25 V / 70.7 V transformer with external screwdriver-adjustable power taps. Low impedance models include SC-610 (10W, 8 ohm), SC-615 (15W, 8 ohm), SC-630 (30W, 8 ohm) and SC-651 (50W, 16 ohm). The SC Series are easy to install in wall, pole or ceiling-mount applications and include corrosion-resistant stainless-steel mounting hardware. The SC Series models are also designed for intercom talk-back applications requiring dual operation as both a microphone and speaker. Each model is a double re-entrant horn with compression driver for high sensitivity and a lightweight aluminum enclosure. The loud-speaker diaphragm is heat and moisture-resistant to prevent deformation and extend operation. The SC Series are also IP-65 standards compliant for dust and moisture-resistance with a wide operating temperature range from -4° F to 130° F.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	TOA
System Type	Horns & Speakers
Non-Domestic Product	No
MPN	SC-610T
Custom Bundle	No
Modified Item	No
Model	TOA SC-610T
UPC	Does not apply
