Toa Vm2240 Amplifier

US $1,600.00

Vancouver, British Columbia, Canada
May 4th

Open on mobile:
QR code

Specification (*3) 0 dB= 1 V Power Source AC: 120 V AC, 50/60 Hz DC: 24 V DC/15 A , M3.5 screw terminal, Barrier distance: 8 mm, Applicable cable diameter: AWG22 - AWG14 Power Consumption on AC Mains With no signal present: 54 W Under normal operating conditions according to EN60065: 1998 sec. 4.2: 255 W With rated output signal: 549 W Current Consumption on 24 V DC Power Input With no signal present: 1 A Under normal operating conditions according to EN60065: 1998 sec. 4.2: 5 A With rated output signal: 14 A Rated Output 240 W Output Voltage /Impedance 100 V/42 ?, 70 V/21 ?, 50 V/10 ? (selectable by the internal wiring change) Frequency Response 50 Hz - 16 kHz Distortion Under 1 % Signal-to-Noise Ratio Over 60 dB Tone Control Bass: 100 Hz ±10 dB, Treble: 10 kHz ±10 dB (Inputs 1 - 3 and BGM individually adjustable.) Remote Microphone /Expansion Amplifier Connection 2 RJ45 female connectors for connecting the RM-200M Remote Microphone and the VM-2120 or VM-2240 unit used as an expansion amplifier. Maximum distance: 800 m in total, Link cable: Category 5 Shielded Number of connectable RM-200M's: Up to 4 Twisted-Pair straight cable (TIA/EIA-568A standard) Input Inputs 1 - 3: -60 dB(*3) (MIC)/-10 dB(*3) (LINE) (changeable), 600 ?, electronically balanced(*4), combined XLR connector (female)/phone jack (Only Input 1 is additionally equipped with DIN connector(*5).) Telephone paging input: Push-in terminal block(*6) Voice sound: -10 dB(*3), 10 k?, electronically- balanced input with shield terminal(*4) Control: No-voltage make contact input, open voltage: 3.3 V DC, short-circuit current: under 1 mA BGM 1 - 2: -20 dB(*3), 10 k?, RCA pin jack, monaural (internally mixed) Power amplifier input: 0 dB(*3), 10 k?, RCA pin jack External speaker line input: 100 V line, for All-Zone Broadcast (This input is selected when the "Unit's broadcast cutoff" control is activated.) Output Speaker output: Plug-in screw connector(*7) 5-zone selector with attenuator (all zones simultaneously selectable) Direct speaker line output: Direct output from the power amplifier output transformer (attenuator bypassed), Plug-in screw connector(*7) Line output: 0 dB(*3), 10 k?, RCA pin jack Recording output: 0 dB(*3), 10 k?, RCA pin jack Preamplifier output: 0 dB(*3), 10 k?, RCA pin jack Control Input For controlling Inputs 1 - 3, Push-in terminal block No-voltage make contact input, open voltage: 3.3 V DC, short-circuit current: under 1 mA Control Input and Output D-sub connector (25-pin, female) Input: No-voltage make contact input, open voltage: 3.3 V DC, short-circuit current: under 1 mA Output: Open collector output, withstand voltage: 30 V DC, control current: under 10 mA (1) External control input Activation of messages(*8) Activation of power Activation and stop of Emergency Broadcast Unit's broadcast cutoff (when activated by an external emergency equipment) (2) Status output Irregularity of communications with the Remote Microphone and an expansion amplifier AC power condition DC power condition Irregularity of the sound source of the Voice Announcement Board Failure (FAULT) indication on Power switch on External Attenuator Control Output Plug-in screw connector(*7), relay, no-voltage make contact output, transfer type, withstand voltage: 30 V DC, 125 V AC, contact current: under 7 A (DC), under 7 A (AC) Surveillance Input and Output(*9) D-sub connector (25-pin, female) Input: No-voltage make contact input, open voltage: 3.3 V DC, Output: Open collector output, withstand voltage: 30 V DC, Power Supply 24 V DC/0.1 A, for supplying power to an optional Amplifier Control Unit RU-2001/-2002, push-in terminal block(*6) Chime Tone Built-in chime: 2-tone chime/2-tone chime (fast repeat)/4-tone chime (Up)/Single-tone chime/4-tone chime (Up & Down)/Gong/off Voice Announcement Board sound source: Pre-recorded chime(*8) Function Two units stacking (VM-2120 or VM-2240) Emergency broadcast (sequential control) Broadcast priority control Surveillance (failure detection) function(*9) Power supply to only one Remote Microphone (RM-200M) Line resistance: Under 40 ? (one way) Operating Temperature 0 °C to +40 °C Finish Panel: ABS resin, dark gray (PANTONE 447C or its equivalent), paint Case: Steel plate, dark gray (PANTONE 446C or its equivalent), paint Dimensions 419 (W) x 143.3 (H) x 355.7 (D) mm Weight 14.5 kg Accessory Power cable…1, Miniature type fuse 8 A…1, Name label…1, Volume cover…4 Option Rack mounting bracket: MB-36 Input transformer: IT-450 Voice announcement board: EV-200M Surveillance board: SV-200MA International Buyers - Please Note: Import duties, taxes, and charges are not included in the item price or shipping cost. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	vm-2240
Country/Region of Manufacture	Japan
