Top Microsystems 550w 7 Output 24 Pin Atx Power Supply Psu W/ Sata & Pci-e

US $2200

San Jose, California, United States
May 30th

Open on mobile:
QR code

This is a new Top Microsystems 550W 7 Output ATX Power Supply P6550E FE2 CONNECTORS INSTALLED: 1 ATX 24 PIN 1 ESP/ATX12X 8-4 2 SATA 10 Molex Style 4 Pin Peripheral 1 PCI-E 4 Pin 1 FDD Built in Power Factor Correction The Power Supply shall incorporate universal power input with active power factor correction, which shall reduce line harmonic current in accordance with the EN61000-3-2 and JETI MITI standards. Short Circuit Protection A short circuit placed on any output shall cause no damage to this unit. The power supply shall shutdown and latch off if the short circuit shown. This latch shall be cleared by toggling the PSON signal or by an AC power interruption. 550 Watts 7 Output ATX, EPS12 Industrial Grade Power Supply With Active PFC (Extended PS/2 type) Input Current 10Amps – 5Amp Input Voltage 100 to 240 VAC Input Frequency 47 Hz to 63 Hz +3.3V at 30A, +5V at 40A, +5VSB at 2A, -5V at 1A, +12V1 at 18A, 12V2 at 18A, and -12V at 1A. Input Waveform The unit is capable of operating with a 10% distorted sine wave input as measured by a distortion analyzer. Its flattopping clipped 10% from the peak value of standard sine wave. A remote +3.3VDC sense line connector allow for accurate control of the +3.3VDC line directly at load. Due to potential voltage drops across the connector and traces leading to the PCB components, it may be advantageous to implement a +3.3V sense line that remotely monitors the +3.3VDC power level at the load. PS-ON is an active low signal that turns on all of the main power rails including +3.3V, +5V, +12V & -12V , -5V power rails. When this signal is held by the PC board or left open circuited, outputs of the power rails should not deliver current and should be held at a zero potential with respect to ground. Power should only be delivered to the rails if PS-ON signal is held at ground potential. This signal should be held at +5VDC by a pull-up resistor internal to the power supply. Over Power Protection The power supply shall shut down all DC outputs when outputs power are overloaded to 110~150% Total Parts will guarantee you're totally happy with your purchase! 14 Day Return Policy if merchandise is in unused condition. We promise to ship your merchandise fast! We promise to send you tracking information immediately when shipped! We promise to respond to your questions and concerns! If you have any questions, concerns or suggestions please contact us through the eBay messaging system. Please take a moment to see our current specials on eBay our other eBay listings. Powered by SixBit's eCommerce Solution
