Toshiba TPD7206F SOP20 Ship from US, US $4.59 – Picture 0

Toshiba TPD7206F SOP20 Ship from US, US $4.59 – Picture 1

Toshiba TPD7206F SOP20 Ship from US, US $4.59 – Picture 2

Toshiba Tpd7206f Sop20 Ship From Us

US $4.59

Tucson, Arizona, United States
Jan 29th

Open on mobile:
QR code

Our mission is to give you the e–components you need without having to deal with long delivery times from China. All of our components are already in the US. You can order 1pcs of any part, there is no minimum for ordering. just place an order and you will have your parts in no time! All components come in brand new condition with a 2 months limited warranty, you have plenty of time replace them if needed. Features z Power MOSFET gate driver for 3-phase DC motor z Built-in power MOSFET protection and diagnosis function: low-voltage protection z Built-in charge pump circuit z Package: SSOP-24 (300 mil) with embossed-tape packing Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum ratings and the operating ranges. Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook (“Handling Precautions”/Derating Concept and Methods) and individual reliability data (i.e. reliability test report and estimated failure rate, etc) Usage Precautions Note 1: Feeding the charge pump voltage to external devices Current can be taken out of the final stage (CPV pin) of the charge pump and fed to external devices without causing any problem. In this case, because the charge pump voltage drops, increase the capacitance of the capacitor connected to the CPV pin. However, this will cause the charging current to the capacitor and, hence, loss in the IC to increase. Therefore be careful not to exceed the allowable loss. Note 2: Heat sink design Because this IC contains a charge pump function, loss in it affects external capacitor capacitance and diode characteristics. It is recommended that the junction temperature, Tj , be judged from the on-voltage of the FAULT pin (open-drain). When VDD is within the range of operating power supply voltages, the FAULT pin outputs a low. For details about on-voltage characteristics, see Tj-VFAULT characteristic curves. Note 3: Dead time setting For arm-shorting input logic, all outputs (UU, VU, WU, UB, VB and WB) are pulled low. When operating in forward or reverse mode, take into account the IC output switching time and the switching time (including temperature characteristic) of the external power MOSFET when setting the dead time. The dead time required for only the IC, not including the external power MOSFET, is 4?s (within all operating power supply voltages and all operating temperatures). Note 4: Shorting between outputs, short-circuit of outputs and VDD pin or short-circuit of outputs and GND pin may cause the IC to break down. Therefore, pay careful attention to the design of output lines and VDD and GND lines. Note 5: Precautions on dry packing After unpacking dry or moisture-proof packing, make sure the device is mounted in place within 48 hours at a temperature and humidity of 30°C and 60% RH or less. Because the device is emboss-taped and cannot be processed by baking, always be sure to use it within the said allowable time after unpacking. Standard tape packing quantity: 2000 devices / reel (EL1).

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Toshiba
MPN	TPD7206F
Model	TPD7206F SOP20
