Touch Probe For Uccnc, Mach3, Linuxcnc, Etc - 10 Foot Cable Length

US $125.00

Rockton, Illinois, United States
Aug 28th

Open on mobile:
QR code

You are bidding on a brand new kinematic touch probe for use with a CNC router or milling machine. This touch probe is useful for edge finding, setting offsets/corners, measuring, or copying/reverse engineering existing parts. The probe can be connected to your machine controlled by UCCNC, Mach3, LinuxCNC, and any other controllers that can accept a 'probe' input that can be configured to be triggered by activation of a simple switch. This touch probe electrically behaves like a normally closed switch which opens on contact, and my be connected and configured to be used with almost any breakout board and controller software. Features of this probe: " shank (useable in CNC routers using " collet) Actuates in X, Y, and Z directions, collect surface scanning data (bed of nails) or perimeter trace Small overall size (body is 1" diameter, 1.25" tall) - great for small sized router machines with minimal Z-travel ! Comes with two interchangeable hardened/ground stainless tips (.045" and .073" diameters provided) Uses standard M3-.5 metric thread for tips, so you can use any standard CMM probe tips if you like (Ruby style probe not included in this sale, picture showing a ruby tipped probe is for reference only to demonstrate compatibility with other styli) Adjustment screws so you can eliminate runout between shank and probe tip (this is important if you want to use the probe for accurate edge finding and locating your spindle relative to a feature on your part.) Detachable 10' cord, makes it easier to set the probe up for adjusting runout and for moving out of way when probe used is finished. (chuck probe in spindle and rotate against a dial indicator to dial it in) Probe tip activation force may be adjusted by replacing internal spring (3 springs: Heavy, medium, and Xtra-light NOW INCLUDED!) You may download a PDF of the touch probe manual from the following link: http://www.craftycnc.com/download/154/ You will receive the probe body, two probe tips (.045" and .073" ball tips), and a 10 foot long shielded cable. The cable includes the connector to connect to probe body on one end, and is left un-terminated on the other end, to be connected to your controller/breakout board by you (with what ever connection you may require). This probe is designed and manufactured by me on my own equipment. I also offer a probing 'wizard' for Mach3 called ProbeIt as well as a NEW UCCNC plugin version of ProbeIt. These are available to freely download and test, and I offer reduced cost licenses for those that also purchase a probe. Please visit www.craftycnc.com for more information. Please ask any questions prior to purchasing. Shipping to continental US via small flat rate box. NO INTERNATIONAL SHIPPING. NOTE: I am required to charge 8.25% sales tax on any purchases sent to an Illinois address.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Brand	CraftyCNC
