Treedix Dso138 Oscilloscope Diy Kit Handheld Digital Oscilloscope 1msps Real-...

US $36.22

Phoenix, AZ, United States
Aug 6th

Open on mobile:
QR code

Treedix DSO138 Oscilloscope DIY Kit Handheld Digital Oscilloscope 1msps Real-Time Sampling Rate 2.4 inch TFT Display The kit uses ARM Cortex-M3 processor (STM32F103C8) and contains a 2.4-inch color TFT display, which can be used as an ARM development test board. High-definition display Let you effectively observe and measure signal waveforms in many occasions such as audio, video synchronization, low-frequency switching power supply, infrared receiving and transmitting. DSO138 oscilloscope is partially open-sourced. Can make a tailor-made software development on the basis of this kit, which can be can be changed to millivoltmeter, data recorder, etc. The variety of components is suitable for students to understand the oscilloscope structure and principles, and do in-line component welding, and chip component welding training.It's easy to assembly The oscilloscope kit is specially designed for professional teaching and training in electronics. Please note that this kit need to be assembled and soldered by yourself. Specification Maximum real-time sampling rate: 1Msps Accuracy: 12 Bit Sampling buffer depth: 1024 bytes Analog band width: 0-200KHz Vertical sensitivity: 10mV / Div – 5V / Div (Progress according to 1-2-5) Input impedance: 1M Maximum input voltage: 50Vpp (1: 1 probe), 400Vpp (10: 1 probe) Horizontal time base range: 10s / Div – 50s / Div (Progress according to 1-2-5) Features: 1. Coupling methods include DC / AC / GND 2. The vertical displacement can be adjusted with instructions 3. With automatic, conventional and single trigger mode, it is convenient to capture instant waveform 4. Trigger on rising or falling edges 5. Trigger level position can be adjusted with indication 6. Observable waveform before trigger (negative delay) 7. Waveform display can be frozen at any time (HOLD function) 8. Comes with 1KHz /3.3V square wave test signal source Package included: 1 x Oscilloscope DIY Kit 1 x Instruction Note: This DSO138 Oscilloscope DIY Kit need to be assembled and soldered by yourself. Shipping We offer FREE shipping on all orders! We ship within Three business days of payment, usually sooner. We use a selection of shipping services such as UPS, FedEx, USPS etc. We only ship to the lower 48 states, no APO/FPO addresses or PO Boxes allowed. Local pickups and combined shipping options are not provided at this time. Return You can return a product for up to 30 days from the date you purchased it. Any product you return must be in the same condition you received it and in the original packaging. Please keep the receipt. Payment We accept payment by any of the following methods: PayPal Please pay as soon as possible after winning an auction, as that will allow us to post your item to you sooner! Feedback Customer satisfaction is very important to us. If you have any problem with your order, please contact us and we will do our best tomake you satisfied. Contact Us If you have any queries, please contact us via ebay. We usually respond within 24 hours on weekdays. Please visit our eBay store to check out other items for sale! Thank you for shopping at our store.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Color	RED
Model	Does not apply
MPN	Does not apply
Brand	Treedix
UPC	765756508025
ISBN	0765756508025
EAN	Does not apply
