Trilithic 860 Dspi Multi-function Cable Analyzer Catv Meter Qam Full 860dspi

US $1,395.00

Toledo, Ohio, United States
Jan 29th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: Trilithic 860 DSPi Multi-Function Cable Analyzer (BC# 18917) With Options: Power Pack QAM Full Enhanced Dig Vid QAM EVS Ethernet Web Browser CM To RJ45 Docsis 2.0, 1.1 Battery Pack AC Adapter/Charger Power Cord User Manual on CD-ROM Carrying Case With Strap Cable TV Installer Starter Toolkit Coax Cable Stripper (Brand New) Gilbert Termination Tool (Brand New) Coax Security Shield Wrench (Brand New) Coax Pocket Toner w/ Battery (Brand New) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Trilithic 860 DSPi Multi-Function Cable Analyzer This Unit Has A Built In Cable Modem!! Installed Options: - Power Pack - QAM Full - Enhanced Dig Vid - QAM EVS - Ethernet - Web Browser - CM To RJ45 - Docsis 2.0, 1.1 Free Cable TV Installer Starter Toolkit Included! - Coax Cable Stripper (Brand New) - Gilbert Termination Tool (Brand New) - Coax Security Shield Wrench (Brand New) - Coax Pocket Toner w/ Battery (Brand New) Working Condition: Excellent Condition: Refubished Calibrated: Yes Warranty: 90 Day Exchange Warranty Test DOCSIS, cable modem performance and VoIP quality analysis DSP technology for quick, accurate measurements and high tech productivity Internet browser and server functions integrate with OSS and Workforce Management Large, easy-to-read display and simple user interface for shorter learning curve Efficient design for long battery life – up to five times that of competing instruments Adaptable platform grows to meet the needs of technicians at every tier The high-performance portable analyzer for the digital age. Now you can use a single instrument for all the critical transmission and signal quality tests you need to install and maintain analog, digital, HSD and VoIP services – without the pauses and boot-up delays of other field analyzers. You can also easily upgrade the 860 DSPi for new applications – right in the field – or add powerful options like high-resolution spectrum analysis, QAM and QPSK constellation displays and a wide range of return path tests, all without impacting size or weight. TraffiControl Feature Enables troubleshooting ingress and impulse noise within an active upstream channel band. QAM Source Mode This is one means for verifying the upstream transmission capability of a particular segment of the network for higher order QAM signals, up to 64 QAM. Many cable systems have stepped from QPSK to 16 QAM and now are moving to 64 QAM for upstream data transmission. 8 VSB functionality This optional feature allows the operator to connect an off air antenna to the 860 DSP input port and read level, MER, BER, and view constellation and equalizer tap information on 8 VSB channels. High speed Throughput This option allows the technician to test upstream/downstream data path throughput to the full range of the bonded channels. This is a valuable tool for verifying provisioning as well as bandwidth availability at customer homes or at key test points in the system. Unsolicited Grant Service (UGS) Provides periodic grants for an upstream service flow without the need for a cable modem to transmit bandwidth requests. Advanced CSO / CTB in-channel functionality Enables in-service testing when used with a 3rd party Line Blanker. Line Viewer Utility This is feature that can be used to verify the line blanking. Frequency Range 5 MHz-1 GHz Accuracy @25° C +/-0.75 dB Over temp (-18 to +50° C): +/-2.0 dB (Analog), +/-2.5 dB (Digital) Resolution 0.1 dB Carrier-to-Noise (In-service, non-scrambled standard channels only) Min Input Level for Full Range +10 dBmV Dynamic Range 50 dB Resolution < 0.5 dB Hum (In-service, non-scrambled standard channels only) Minimum Input Level 0 dBmV Range 0 to 5% Resolution 0.1% Accuracy +/- 0.5% Depth of Modulation (In-service, non-scrambled standard channels only) Range 50 to 100% Resolution 0.5% Audio Demodulation FM Carriers Tilt Max Number of Carriers 10 Hi / Lo Delta Resolution 0.1 dB Scan Video, Audio, Pilot, and Digital Carriers; includes total power measurement Forward (Sweepless) Sweep Mode Frequency Range 4 MHz to 1 GHz Display Span User definable Display Scale 1, 2, 5, or 10 dB/division Display Range 6 vertical divisions Sweep Rate (78 channels) ~ 500 ms Spectrum Mode Spans User selectable in 10 kHz steps Display Scale 1, 2, 5, or 10 dB/division Range 7 vertical lines Detection & Dwell Selectable Detector Modes (Narrow or Wide) and Dwell Time Spurious Free Dynamic Range 60 dB @ 25° C (+50 dBmV) Sensitivity -40 dBmV (5 MHz to 1 GHz) Zero Span Mode Video Bandwidth Digital averaging Resolution Bandwidth 10, 30, 100, & 300 MHz; 1, 3 MHz Pulse Measurement Accuracy Nominal level in < 7 ms, +/- 2 dB for nominal in 4 ms (300 kHz RBW) Sweep Times 50 ms to 20 sec in 1, 2, 5 settings Intermodulation Distortion (CSO/CTB) Range = 60 dB Resolution 0.1 dB QAM Measurements Modulation Types ITU J.83 Annex A, B, C QPSK, 16, 32, 64, 128, & 256 QAM(at symbol rates from 2 MSPS to 6.9 MSPS) Measurable Input (Lock) Range 64 QAM: -20 to +50 dBmV (typical) 256 QAM: -15 to +50 dBmV (typical) Frequency Tuning 5 MHz to 1 GHz BER (64 & 256 QAM, pre & post FEC) 10-4 to 10-9 MER 64 & 256 QAM, 6 MHz Channel Bandwidth: Range: 21 to 38 dB, Accuracy (typical): ±1.5 dB 64 & 256 QAM, 8 MHz Channel Bandwidth: Range: 21 to 35 dBAccuracy (typical): ±2.0 dB EVM 64 QAM, 6 or 8 MHz Channel Range: 1.1% to 8.1% Accuracy: ±0.5% (1.1 to 2.0%) ±1.0% (2.1 to 4.2%) ±1.6% (4.3 to 8.1%) 256 QAM, 6 or 8 MHz Channel Range: 1.1% to 5.3% Accuracy: ±0.5% (1.1 to 2.0%) ±0.8% (2.1 to 4.2%) QAM Level Measurement Signal Types QPSK; QAM (16, 32, 64, 128, & 256) Range -40 to +50 dBmV Accuracy @ 25° C +/- 1.25 dB Power Source Charging Time 4 Hours Operating Time, Continuous Use ~4 hours Physical Weight 4.75 lbs. Operating Temperature Range -18 to +50° C (0 to 122° F) Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. --> This item is subject to a FIXED SHIPPING price. This means that the shipping fee will be the displayed amount for all ship-to destinations shown. This item is eligible for pickup unless otherwise stated. We do not ship to any destinations that are not specified here. Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do/do not cover this cost for all of our US customers. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept payment transactions via our online checkout system! Our checkout process is designed that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through our online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hrs upon receipt of payment from the winning bidder. A Shipment Tracking number will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Terms: All transactions are final. Winning bidder assumes all risk of liability with respect to the purchase of the product. Thank you WE ACCEPT ALL MAJOR CREDIT CARDS Put your listings on autopilot with Kyozou eBay Listing Management Software

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Model	860 DSPi
Manufacturer	Trilithic
