Trimble Sps610 Dr 5" Robotic Total Station W/ Trimble Recon Lm80 & Prism Sps 610

US $15,995.00

Allen Park, Michigan, United States
Aug 11th

Open on mobile:
QR code

Michigan based company with a global presence. We ship worldwide to thousands of satisfied customers. Offering Same-Day Shipping & pickup for metro Detroit area land surveyors, civil engineers, architects, excavating & construction companies at our local store in Allen Park, MI. Our equipment is backed by exceptional customer service and support, along with a full warranty. Offering New & Refurbished Total Stations, GPS / GNSS Base & Rovers, Radios, Antennas, Data Collectors, Grade & Pipe Lasers, Digital Levels, Magnetic Locators, Grade Control Systems, AgGPS Systems, Field Supplies, Accessories, Hand Tools & Safety Equipment! Included Items Item Description Shipping Info Payment Info * Trimble SPS610 Robotic Total Station [ID- X2196-L/T*] - 2.4 GHz Radio * Trimble Recon Field Controller [ID- X2194-L/T*] - Trimble LM80 Version 4.21 * Trimble Battery Charger 57550-00 [ID- X2195-L/T*] * Trimble External Radio 68060019 [ID- X2197-L/T*] * Trimble 58128001 Prism [ID- X2198-L/T*] * Trimble Tripod [ID- X2200-L/T*] * Trimble Prism Pole [ID- X2199-L/T*] * Trimble 53002021 Cable * Trimble 73840019 Cable * RS232 Power Cable * Trimble 57013007 Laser Adjustment Plate * QTY. 2 Antennas * QTY. 4 Battery Packs * QTY. 2 AC Adapter/Chargers * Power Cord * QTY. 2 Hard Carrying Cases Condition: Refurbished Warranty: 90 Day Exchange Trimble SPS610 Robotic Total Station w/ Trimble Recon Field Controller w/ Trimble LM80 Version 4.21 - 2.4 GHz Radio Trimble SPS610 Robotic Total Station The versatile solution for site measurement, stakeout, and reflectorless measurement needs With cable-free operation in Autolock, Servo or Robotic modes, the Trimble® SPS610 Total Station is the straightforward solution for site measurement, stakeout, and reflectorless measurement needs. This versatility provides the contractor with an easy-to-set up, easy-to-use positioning sensor that increases productivity in the field. The SPS610 Total Station takes very little setup time and requires only two known points to establish position and orientation. Not only does the SPS610 Total Station provide superior tracking, but the single-person robotic operation increases cost savings and productivity. Precise Measurement The Trimble SPS610 Total Station is a 5” instrument in both the horizontal and vertical angles. Available in Servo, Autolock, or Robotic models, it offers DR Standard for precise prism and reflectorless distance measurement and an Autolock and Robotic range of 300 meters in any direction from the instrument. Trimble MultiTrack Technology The SPS610 Total Station allows you to assign a unique target identifier to the target being used providing you with the confidence that the instrument will lock and track only the correct target. All other reflective objects and targets on the jobsite are ignored, guaranteeing no operation interruptions or incorrect measurements. Market-leading Trimble Technology Exclusive Trimble MagDrive™ servos provide quiet, effortless operation and the fastest, most responsive and accurate tracking available today. Unique Trimble SurePoint™ technology autocorrects instrument pointing for mislevelment and internal calibrations in real time. You will never again record information only to find that your instrument wasn’t level. Tracking the target at short range or in areas where the rate of angular change is high always creates a challenge. Having fast servos allows the instrument to track more reliably. The Trimble SPS610 Total Station uses patented Trimble MagDrive fourth generation servo technology, which uses electro-magnets to eliminate direct drive and friction from the servo system. Combined with the USB communications network for the fastest command response time, the system delivers the fastest tracking, fastest turning, most responsive instrument available. Total stations depend on being level to deliver accurate results. When an instrument is knocked, buffeted by wind, or subjected to ground vibration, its level is affected. Dual-axis compensation corrects the angle measurement system for mislevelment, but doesn’t change the instrument's pointing to account for the associated errors. Patented Trimble SurePoint technology not only corrects the angles for mislevelment, it also continually adjusts the instrument’s pointing to deliver the most accurate automated positioning available. Direct RefleX Reflectorless Measurement The Direct Reflex reflectorless measurement capability allows you to quickly and safely measure hard-to-reach or unsafe places up to 150 m (492 ft) away. There is no need to walk the surface with a target. You’ll realize significant increases in productivity when measuring bridges, culverts, concrete surfaces, and structures. Powered by Trimble SCS900 Site Controller Software The power of the Trimble SPS610 Total Station is unleashed through the software that drives it. Trimble SCS900 has been developed as a contractor’s tool, to provide simple, easy-to-understand workflows that are dedicated to the construction jobsite. Combined with Trimble Intelligent Data Tracking technology, SCS900 will meet all of your stakeout, measurement, grade control, and quality control requirements. Features: DR Standard reflectorless measurement capability allows high accuracy measurement to vertical surfaces and inaccessible points without the risk and delay of a sending a person to dangerous locations. Trimble MagDrive™ servos provide unmatched instrument turning and tracking speeds Trimble SurePoint™ technology autocorrects instrument pointing for mislevelment so you’ll always capture accurate 3D information Unique Trimble MultiTrack™ technology allows operation with conventional prisms or active targets Servo controls and telescope focus are located on the instrument side panel, providing convenient, ergonomic, one handed operation Long battery life allows over six hours robotic operation on one smart lithium ion battery Specifications: Angle Measurement Horizontal Accuracy 5" (1.5 mgon) Vertical Accuracy 5" (1.5 mgon) Angle Reading (least count) Standard 1" (0.1 mgon) Tracking 1" (0.1 mgon) Automatic level compensator Dual-axis compensator ±6' (±100 mgon) Distance Measurement Accuracy (Standard Deviation) Prism Mode Standard ± (2 mm + 2 ppm) ± (0.01 ft + 2 ppm) Tracking ± (5 mm + 2 ppm) ± (0.032 ft + 2 ppm) Dynamic Measurement Capability Synchronized angle and distance measurement No Maximized position update rate 2.5 Hz 3D Positioning Accuracy Note: 3D positioning accuracy is based on the following parameters: Angle accuracy (horizontal and vertical position accuracies vary with range measured and vertical angle) Distance measurement accuracy (ppm error causes accuracy to vary with range measured) Tracker lock on accuracy Static or moving target Leveling Circular level in Tribrach 8'/2 mm (8'/0.007 ft) Electronic 2-axis level in the LC- display 0.3" (0.1 mgon) Servo system MagDrive servo technology, integrated servo/angle sensor electromagnetic direct drive Rotation speed 115 degrees/sec (128 gon/sec) Positioning speed 180 degrees (200 gon) 3.2 sec Clamps and slow motions MagDrive servo-driven endless fine adjustment Centering Centering system Trimble 3-pin Optical plummet Alidade optical plummet Magnification/shortest focusing distance 2.3/0.5 m–infinity (1.6 ft–infinity) Telescope Magnification 30 Aperture 40 mm (1.57 in) Field of view at 100 m (328 ft) 2.6 m (8.5 ft) Shortest focusing distance 1.5 m (4.92 ft)–infinity Illuminated crosshair Variable (10 steps) Trimble Tracklight® built in Standard Operating temperature –20 C to +50 C (–4 F to +122 F) Dust and water proofing IP55 Focus type Servo assisted on side cover Power supply Removable Internal battery Rechargeable Lithium-ion battery 11.1 V, 4.4 Ah Operating time One internal battery Approximately 6 hours Three batteries in multi-battery adapter Approximately 18 hours Trimble CU Robotic holder with one internal battery Approximately 12 hours DR Reflectorless Mode Standard measurement ± (3 mm + 2 ppm) ± (0.01 ft + 2 ppm) Tracking ± (10 mm + 2 ppm) ± (0.032 ft + 2 ppm) Measuring Time - Prism mode Standard 2 s Tracking 0.4 s Measuring Time - DR Mode Standard 3-15 s Tracking 0.4 s Range (under clear conditions) Prism Mode 1 prism 1 prism Long Range mode 3 prism 3 prism Long Range mode Shortest possible range 3,000 m (9,800 ft) 5,000 m (16,400 ft) max range 5,000 m (16,400 ft) 7,000 m (23,000 ft) max range 1.5 m (4.9 ft) DR Mode Kodak Gray Card (18% reflective) >120 m (394 ft) Kodak Gray Card (90% reflective) >150 m (492 ft) Concrete 80-150 m (262-492 ft) Wood construction 80-180 m (262-590 ft) Metal construction 80-120 m (262-394 ft) Light rock 80-120 m (262-394 ft) Dark rock 60-80 m (197-262 ft) Reflective foil 20 mm 600 m (1,968 ft) Reflective foil 60 mm 1200 m (3,937 ft) Shortest possible range 1.5 m (4.9 ft) Light source Laserdiode 660 nm Laser class 1 in Prism mode Laser class 2 in DR mode Laser pointer coaxial (standard) Laser class 2 Beam divergence - Prism mode Horizontal 4 cm/100 m (0.13 ft/328 ft) Vertical 4 cm/100 m (0.13 ft/328 ft) Beam divergence - DR mode Horizontal 2 cm/50 m (0.066 ft/164 ft) Vertical 2 cm/50 m (0.066 ft/164 ft) Atmospheric correction 130 ppm to 160 ppm continuous Weight Instrument (Servo/Autolock 5.15 kg (11.35 lb) Instrument (Robotic) 5.25 kg (11.57 lb) Trimble CU controlle 0.4 kg (0.88 lb) Tribrach 0.7 kg (1.54 lb) Internal battery 0.35 kg (0.77 lb) Trunnion axis height 196 mm (7.71 in) Handle Detachable and eccentric for unrestricted sighting Robotic measurement Range Robotic 300 m (984 ft) Autolock 300 m (984 ft) Shortest search distance 0.2 m (.65 ft) Autolock pointing precision at 200 m (656 ft) <2 mm (0.007 ft) (Standard deviation) Angle reading (least count) Standard 1" (0.1 mgon) Tracking 1" (0.1 mgon) Averaged observations 0.1" (0.01 mgon) Type of radio internal/external 2.4 GHz frequency-hopping, spread-spectrum radios Search time (typical) 2–10 s Search area 360 degrees (400 gon) or defined horizontal and vertical search window Tracker Performance Coaxial with telescope Yes Passive tracking capability Yes Active target capability Yes Number of Target ID channels 8 Automatic lock on sighting prism Yes Trimble Recon Data Collector The new-generation Trimble® Recon® handheld is as tough as ever...with an IP67 rating, it’s impervious to water and dust. And inside the rugged casing, it’s packed with connectivity options. As well as non-volatile memory, and an industry-standard, open operating system, you have built-in Bluetooth® and wireless LAN. With all of this, the Trimble Recon handheld is simply the best-connected, lightweight and ultra-rugged field computer available. The Trimble Recon handheld features a high-performance 400 MHz processor, an improved screen that’s readable in direct sunlight, and a built-in microphone. The system provides two CompactFlash (CF) slots, letting you add GPS cards, barcode scanners and other devices—or add a memory card if you want to take additional data into the field. Connectivity Options Bluetooth lets you connect to mobile peripherals without cables, and wireless LAN gives you access to local area networks, email and the Internet. You can use Bluetooth to connect wirelessly to other devices such as a laser rangefinder, or if you need to navigate or map assets for your GIS, the Trimble Recon handheld connects seamlessly with Trimble’s GPS Pathfinder® receivers. If you are within range of a Wi-Fi network, the built-in wireless LAN in your Trimble Recon handheld makes it very easy to send and receive data—as soon as you arrive at a Wi-Fi hotspot, such as your office or work depot, you can quickly and securely transfer large amounts of data into the network. Cellular connectivity can be added to the Trimble Recon handheld via the TDL 3G cellular modem. Connecting via wireless LAN or Bluetooth, the TDL 3G provides continuous network/internet access to real-time map data, web-based services, and live update of field information. Industry-standard software The Trimble Recon handheld is powered by the Windows Mobile® version 6 operating system—so you can choose the software that matches your workflow, whether it's off-the-shelf or purpose-built. And because all your data and applications reside in persistent storage, they are secure even in the event of power loss. Rugged and reliable Designed for the realities of mobile GIS field work, the Trimble Recon is a rugged and reliable handheld which connects seamlessly with Trimble GPS receivers. Mobile technology is changing fast, but the Trimble Recon handheld is designed with the future in mind—its open operating system, expandable storage and flexible connectivity deliver all you need, and more, in the most rugged, reliable solution available. Features Ultra-rugged and lightweight Integrated wireless connectivity (Bluetooth and wireless LAN) GPS functionality easily added Windows Mobile version 6 operating system Specifications: Standard features • Windows Mobile version 6 operating system • 1 x Type I and 1 x Type I/II CompactFlash (CF) slots for memory expansion and the addition of accessories • Outdoor color display • Rugged and waterproof design • Integrated speaker and microphone • 400 MHz Intel PXA255 XScale processor • 256 MB non-volatile Flash data storage • Integrated Bluetooth1 wireless technology for connectivity to other device • Integrated 802.11g wireless LAN for local network connectivity Software • Microsoft® ActiveSync® , Microsoft Office Mobile (Word Mobile, Excel Mobile, OneNote Mobile, PowerPoint Mobile), Internet Explorer Mobile, File Explorer, Windows Live® Messenger, Windows Media Player, Pictures & Videos, Outlook Mobile, Contacts, Calendar, Tasks, Calculator • Bluetooth File Transfer • Transcriber (handwriting recognition) Technical specifications Physical Size 16.5 cm 9.5 cm 4.5 cm (6.5 in 3.75 in 1.75 in) Weight 0.49 kg (17 oz) with battery module Processor 400 MHz Intel PXA255 XScale CPU Memory Nonvolatile NAND Flash 256 MB (~31 MB reserved) Battery Internal 3800 mAh NiMH, rechargeable in unit Environmental Operating temperature –30 °C to +60 °C (–22 °F to +140 °F) Storage temperature –40 °C to +70 °C (–40 °F to +158 °F) Humidity MIL-STD-810F, Method 507.4 Sand and dust IP67, MIL-STD-810F, Method 510.4, Procedures I and II Water. IP67, sealed against accidental immersion (1 m for 30 min) MIL-STD-810F, Method 512.4, Procedure I Drop. 1.22 m (4 ft), MIL-STD-810F, Method 516.5, Procedure IV 26 drops from 1.22 m (4 ft) onto plywood over concrete 6 additional drops at -30 °C (-22 °F) 6 additional drops at 60 °C (140 °F) Vibration Vibration resistant, MIL-STD-810F, Method 514.5 Altitude MIL-STD-810F, Method 500.4, Procedures I, II & III 15,000 ft at 23 °C (73 °F) Input/output Expansion 1 Type I and 1 Type I/II CF slot CF-Cap seal protects from rain, wind, and dust Display 240 320 pixel ( VGA) color TFT with LED front light Interface TFT touch screen, 10 hardware control keys Soft Input Panel (SIP) virtual keyboard and Transcriber software Audio system events, warnings, and notifications Communications Bluetooth, 802.11g wireless LAN DE9 (M) RS-232 serial port, USB-slave port We will attempt to ship your item(s) within 24 hours after payment has been received. Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you Sell Smarter with Kyozou. Inventory and Ecommerce Management

Condition:	Seller refurbished: The item has been restored to working order by the eBay seller or a third party. This means the item was inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See seller’s listing for full details. ...	Brand	Trimble
Model	SPS610
MPN	SPS610
