Included Items Item Description Shipping Info Payment Info * Trimble TDL 450H 430-473 MHz Radio Modem P/N: 74450-65 [ID- X1499] * GPAC P2 Power Cable w/ LEMO Condition: Refurbished Warranty: 90 Day Exchange Trimble TDL 450H 430-473 MHz Radio Modem P/N: 74450-65 Trimble TDL 450H Radio Designed to support all aspects of GNSS surveying, the Trimble® TDL 450 series offers flexible configuration options and rugged reliability. This sophisticated radio modem places Trimble’s newest low power data link technology in your hands. For surveyors that need to make the most of every day, the Trimble TDL 450 series is a giant step forward in radio technology Field Configurable and Built to Last The Trimble TDL 450 series is an advanced, high speed, wireless UHF data radio built to endure the stresses of daily use in harsh conditions. Full metal construction provides impact and weather resistance that will keep you working with complete confidence. The full-function user interface streamlines field configuration and troubleshooting so you can maintain maximum productivity. Adapt as conditions require: for longer baselines you can dial up the power, and when the work area is smaller, a lowerpower output extends battery life. The Trimble TDL 450 series even provides access to diagnostic data in the field. So, you can solve signal strength challenges and make adjustments to stay more productive. Performance features: High Over-the-Air Link Rate: 19,200 bps (both GMSK and 4FSK) Supports 1 Hz RTK corrections for multiconstellation receivers Configurable Transmit Power: Trimble TDL 450H power settings: 4 user-defined power levels from 2 W to 35 W Configurable from the front panel up to the maximum power output setting for your region Available Bandwidth: 410 MHz to 430 MHz and 430 MHz to 470 MHz models Designed for high performance over the entire band Software-controlled Channel Bandwidth: Software configurable for both 12.5 kHz and 25 kHz radios Versatility, for Continuous Productivity Easy-to-use and highly reliable, the Trimble TDL 450 series radio is capable of broadcasting, repeating and receiving real-time data used by Trimble GPS/GNSS receivers. Its compact size allows it to be easily mounted on the same tripod as the receiver or on its own tripod using mounting hardware included as standard equipment. As a transmitter, the Trimble TDL 450 series seamlessly broadcasts corrections to radios and radio-enabled devices. Network coverage can be enhanced by the use of one or two repeaters. As a repeater, the TDL 450 series enables you to reach inaccessible or obstructed locations due to its extended range and seamless coverage around obstacles. Because it is so versatile, one extra radio can be used as a backup or as a “spare” for multiple tasks. Specifications: GENERAL Communication 1 RS-232 port, 115.2 kbps maximum User Interface 5 navigation buttons with 2-row, 16-character LCD display; English, Russian and Chinese language support Power External 9.0 V DC to 30.0 V DC, 15 Amp maximum During RX 1.7 W nominal @ 12.0 V DC During TX 130 W nominal @ 12.0 V DC, 35 W RF output 55 W nominal @ 12.0 V DC, 8 W RF output 8 W nominal @ 12.0 V DC, 1 W RF output Modem Specifications Link Rate/Modulation 19,200 bps/4FSK, 9600 bps/4FSK, 19,200 bps/GMSK, 6,000 bps/GMSK, 9600 bps/GMSK, 8000 bps/GMSK, 4800 bps/GMSK Link Protocols Transparent EOT/EOC/FST, Packet-Switched, TRIMMARK™ , TRIMTALK™ , TT450S (HW), SATEL® Forward Error Correction Yes Radio Specifications Frequency Bands 410 MHz to 430 MHz and 430 MHz to 473 MHz Frequency Control Synthesized 6.25 kHz tuning resolution; Frequency stability ± 1 ppm –40 °C to +85 °C (–40 °F to +185 °F) RF Transmitter Output Programmable from 2 W to 35 W (where permitted) Sensitivity –110 dBm BER 10–5 Type Certification All models are type accepted and certified for operation in the U.S., Europe, Australia, New Zealand, and Canada. Environmental Specifications Enclosure IP67 (Dustproof and watertight to depth of 1 m for 30 minutes) Operating Temperature (receiver) –40 °C to +65 °C (–40 °F to +149 °F) Operating Temperature (transmitter) –40 °C to +65 °C (–40 °F to +149 °F) Storage Temperature –55 °C to +85 °C (–67 °F to +185 °F) Vibration MIL-STD-810F M Mechanical Specifications Dimensions 11.9 cm L x 8.6 cm W x 21.3 cm H with handle (4.7 in L x 3.4 in W x 8.37 in H with handle) Weight 1.95 kg (4.3 lb) Data/Power Connector 5-pin, #1-shell LEMO RF Connector 50 Ohm, TNC female We will attempt to ship your item(s) within 24 hours after payment has been received. Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you Reach your goals with Kyozou eBay Sales Management
