Tt1000 Welding Rotator / Turntable

GBP 1,199.00

YORK, North Yorkshire, United Kingdom
Jan 30th

Open on mobile:
QR code

TT1000 TURNTABLE / ROTATOR As standard the TT1000, supplied with a foot switch to stop & start the rotation. On the control panel there is a switch to select clockwise or anticlockwise rotation, a knob to control the speed & a high-low speed range switch for more accurate setting. The turntable can be positioned to any angle between horizontal & 90 degrees, a hand wheel which drives a worm gear is fitted at the rear to adjust this angle, a lock off device is fitted to prevent the table being accidentally moved or knocked off angle. The table is machined with 6 slots 90X12mm for mounting jigs or the chuck. The table is also scored every 30mm with a circle to assist in accurate setting up of the job. Under the table is a substantial brass bush arrangement for the welding earth return and we supply a 2M welding lead attached to this. TECHNICAL SPECIFICATIONS TT1000 Input Voltage: 110V / 230V Max welding current: 450A @ 60% Max load – turntable in the horizontal position: 100KG Max load – turntable in the vertical position 50KG Rotation speed: 0.2 – 15 rpm Table diameter 345mm Dimensions: Height 420mm Width 430mm Length 440mm Larger models of turntables upto 300KG are available. Please contact us for further details Other Optional Functions (available at extra cost) 3 Jaw, self centreing, quick release chuck. Remote socket for stop / start to interface with a robot, welding machine, etc Control to give automatic start and stop of rotation with the welding current. Foot pedal to give stop start of the rotation with variable speed control on the pedal and start of the power source as well if required. Timer control (for pool delay or spot welds, etc) & an output to drive the power source, so only one control signal is needed to start the whole process. TT1000P rotator for more torque and accurate speed control at lower speeds. Ideal for tig welding procedures. Optional taco feedback for rotating uneven loads with no speed variation. Please enquire for further possibilities. All models are protected from HF interference. Fully automated systems also built please enquire for further possibilities. A 3 Jaw, self centring, quick release chuck is available for this turntable. please see my other listings. ONE YEAR (RTB) WARRANTY INCLUDED. PLEASE VIEW OUR OTHER ITEMS FOR SALE INCLUDING VARIOUS OTHER MIG AND TIG TORCHES, AND A UNIVERSAL WIRE FEED ASSEMBLY KIT, AND GAS SOLENOIDS. TEC ARC is a leading manufacturer and repair centre of arc welding machines. We have been designing, building and repairing all types of welding equipment in the UK for over 20 years. All new machines are built to a very high standard, using quality components and all comply with CE requirements. New machines are sold with a 1 year return to base warranty. Conditions of return to base (RTB) warranty are as follows: The machine will be repaired free of parts and labour for 1 year from the date of dispatch from our works. The purchaser is responsible for shipping charges to us. Tec arc will pay for return to the customer. There will be a charge if the fault or damage has been caused by mis-use by the purchaser or if no faults can be found with the machine. Because we design and manufacture welding machines, parts are kept in stocked, on our premises, and full technical back up is given if required. Any of our products can be demonstrated and collected at our premises: Technical Arc Services, Outgang Lane, Osbaldwick. York. YO19 5UP. Any further information you require about us or our products please email me at les-ford@tiscali.co.uk or Tel: 07725206129. Delivery is ?20.00 to most main land UK destinations. Please contact us for cost to other destinations. For card payment please contact me on 07725206129. Business seller information TECHNICAL ARC LTD Contact details LES FORD OUTGANG LANE OSBALDWICK YORK North Yorkshire YO19 5UP United Kingdom Phone:0772|5206129 Email:ebay@technicalarc.co.uk Value Added Tax Number: UK 598855849 Return policy To qualify for a hassle-free return, you must pay with PayPal and have the item shipped to a US address. The item must be returned in the same condition it was received. See terms and conditions - opens in a new window or tab. After receiving the item, open a return within Return shipping 14 days You pay return shipping
