Tube Bender: 3-1/2" Pines No. 2, Horiz., Mandrel Extractor, CW Rotation, 1967, US $16000 – Picture 0
Tube Bender: 3-1/2" Pines No. 2, Horiz., Mandrel Extractor, CW Rotation, 1967, US $16000 – Picture 0

Tube Bender: 3-1/2" Pines No. 2, Horiz., Mandrel Extractor, Cw Rotation, 1967

US $16000

  • Chicago, Illinois, United States
  • Jun 22nd
Open on mobile:
QR code
3-1/2" PINES Mandrel-Type Horizontal Tube Bender, Model No. 2, S/N 11255-67019, New 1967 Specifications: Maximum radius(standard):...........................................................12" Maximum tube length over mandrel:..................................................7'5" Average maximum bending arm speed:..............................................5.5 rpm Standard operating pressure:................................................. 2,000 psi Height from floor to centerline of bending arm:.................................... 47" Bending capacities-I.P.S. extra heavy pipe:......................................... 2"                   -Non-ferrous tubing:..... Y.P. to 25,000 psi 3-1/2" O.D. x .120" wall                   -Steel tubing:........... Y.P. to 40,000 psi 3-1/2" O.D. x .083" wall                   -Stainless steel tubing:....  Y.P. to 60,000 psi 3" O.D. x .065" wall                   -Steel bar round:...................... Y.P. to 40,000 psi 1-7/8" dia                   -Steel bar square:....................... Y.P. to 40,000 psi 1-11/16"                    -Angle bar:........................Y.P. to 40,000 psi 3" x 3" x 5/16" Maximum bend angle plus overbend for springback:............................180 degrees Bend angle accuracy:.....................................................+/- 1/4 degree Electrics:....................................................... 7-1/2 HP/220-440/3/60 Overall Dimensions (Approx.):..........................................14'L x 5'W x 4'H Weight (Est.):...............................................................4,500 Lbs. Equipped With: Clockwise rotation Oil reservoir in bed Hydraulic Mandrel Extractor Pressure Die Assist  8-Station Turret Degree-of-Bend Selector Bijur Automatic Lubrication System  Motor and Electrical Controls. F.O.B. Chicago, IL
