Untitled Document Welcome to E-city2008 store TV/PC/HDMI/CVBS/RF/USB/AUDIO Controller Board For B133EW04 V.4 V4 1280*800 Remarks: Only Fit for V.4 Version, If other Version, pls contact us before purechase This LCD controller board can support TV. It can support LCDs below 42 inch with a LVDS interface and a resolution lower than 1920*1080. This is LCD Controller Board kits for N133IGE-L41 LP133WX2 TLA1 TLG6 lcd screen, checked it fine before ship out Please view the shipping details before ordering it,thanks Features: Chipset TSUMV59XU/TSUMV59XE Panel interface 1ch 6bit/ 1ch 8bit/ 2ch 6bit/2ch 8bit Power supply 12V Voltage to panel 3.3V/5V/12V Standby <1W Max resolution 1920*1080 8.9"-42" LVDS panel OSD language Chinese/English/French/Germany…(customizable,usually English) Size of controller board: 190mmX43mmX15mm Key Function Menu,CH+,CH-,VOL+,VOL-,INPUT,POWER Have a try and you will get great surprise! Then, are you going to get this kit? Important Steps to Process your order with this kit: Step 1: Please provide your LCD panel model no. by sending us the ebay message before bidding this item, so that we can advise a right kit for your LCD. (Usually, the model no. can be found on a sticker on the back of the LCD panel. If needed, disassemble the plastic shell and you will find the sticker). If possible, please give us as more specification of your LCD as you can. Then wait for our reply. Step 2: We will give you the reply as soon as possible after carefully selecting and testing the kit by our technical support, and then you can place the order, and pay for it. We will send the package via E-packet to the customers from USA,and other customers we will send it by register air mail as soon as possible after cleared payment. (If you prefer express shipping, please contact us to pay additional shipping cost before payment.) Step 3: Waiting for the package. We will write corresponding program into the lcd controller board to match your LCD, so this kit will match against one very specific LCD Panel or others that have exactly the same specification. However, a programmer could help on different LCDs, that is, change the firmware of the LCD controller board by yourself. Be aware that different LVDS cables and Inverters will be needed to match different LCDs. Notes: 1. Please make sure that your LCD is ok before bidding this item, else you will be responsible for the incompatibility. 2. If you concern much about resolution setting, please reconsider before bidding! 3. We will try our best to prepare the right kit for you, such as writing the corresponding program into the controller board, selecting the suitable LVDS cable and the suitable inverter. But as we don't have an LCD exactly as yours at hand, we can just test the controller with our own LCD. For yours, you need to test it yourself to check if it works well or not. As you know, there are so many LCDs with many varieties in the market, sometimes we can't promise the exact compatibility. Please consider it before bidding! However, we have gained many success in preparing the kit for our customers in real store. So why not have a try to get surprise! 4. If you are not specialized in electronics or have doubts in operation, please contact us for instruction, as we are not able to responsible for wrong operation. 5. After finishing the connecting, please don't rush to power on! First, use multi-meter to test whether the GND of the LCD is connected with the GND of the controller board. If not, please check the connection again. If yes, please test whether there is a short circuit between the red wires and black wires of the LVDS cable. If there is a short circuit, it means opposite connection or other errors. Any problem, please feel free to contact us. DIY needs a certain professional knowledge, please kindly take the responsibility of the risk. No metal contact is allowed when powering on the controller board, otherwise short circuit may occur, which may cause unavailability of the controller board. Package Includes: 1xA.VST29.03 controller board 1x Remote controller 1x keyboard with receiver 1x LVDS cable 1XLED Inverter Need Power supply AC Adapter: http://stores.ebay.com/E-city2008/_i.html?_nkw=12v+4a&submit=Search&_sid=734424412 Need VGA Cable: http://stores.ebay.com/E-city2008/_i.html?_nkw=vga+cable&submit=Search&_sid=734424412 Need lvds cable: http://stores.ebay.com/E-city2008/_i.html?_nkw=lvds+cable&submit=Search&_sid=734424412 Need keypad: http://stores.ebay.com/E-city2008/_i.html?_nkw=keypad&submit=Search&_sid=734424412 Need inverter: http://stores.ebay.com/E-city2008/Inverter-/_i.html?_nkw=inverter+board&submit=Search&_fsub=4702506012&_sid=734424412 Other resolution controller board: http://stores.ebay.com/E-city2008/Controller-board-/_i.html?_fsub=4930423012&_sid=734424412&_trksid=p4634.c0.m322 Payment: 1.We accept paypal payment only,If you have any question,contact us by email. 2.Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility Shipping 1. WORLDWIDE SHIPPING.(Except Belgium, Luxembourg, Italy, Germany, China and Croatia) 2. Orders processed within 24-48 hours of payment verification(The Saturday/Sunday and most national holidays are excluded) 3. We ship to confirmed paypal address only,Pls confirm your address is correct and complete before finished order. 4. If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction! 5. Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery. 6. Delivery time Country Delivery Time Working Days(not including holiday) 5-7 8-11 12-14 15-19 20-22 >22 Working Days + Saturday + Sunday 5-9 10-15 16-20 21-25 26-30 >31 United States Rate (item arrived) 5.10% 50.10% 29.60% 10.50% 4.70% Refund United Kingdom Rate (item arrived) 9.90% 63.20% 19.10% 3.40% 4.40% Refund Australia Rate (item arrived) 21.40% 50.00% 14.30% 7.20% 7.10% Refund France Rate (item arrived) 10.50% 28.60% 43.80% 10.10% 7.00% Refund Germany Rate (item arrived) 11.10% 22.20% 30.30% 20.90% 15.50% Refund Canada Rate (item arrived) 0.00% 47.10% 31.40% 17.60% 3.90% Refund Spain Rate (item arrived) 3.50% 25.00% 47.90% 12.90% 10.70% Refund Note:Other countries or remote areas may take longer. Effective Communication and Warranty 30 days money back: Within 30 days after you receive the item, you can contact us for any problem any time for 30 days warranty Remarks: any buyer who open dispute or give negative feedback is taken to give up their warranty, then we will require all proof from you and let ebay/paypal make decision .
