Two-channel Temperature Humidity Data Logger Recorder Usb -35c-80c 32k Readings

US $69.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

This data logger measures and stores up to 32,000 humidity(0 to 100%RH) and temperature(-35 to 80C(-31~176F)) readings. Dew point and more professional applications can be provided by the PC software DGraphTM. Logger status, alarm indication and low battery indication are via flashing red/green LED and yellow LED. The button on housing can be used to start logging, or confirm and clear LED alarm when LED alarm is hold status. User can plug data logger straight into PC’s USB port without any cables. Before getting started, user need to install USB driver and DGraphTM software, provided on the CD which is included in product packing box. All the software can run under Windows XP, Vista, 7 or 8(32 bit and 64 bit Versions). User can easily use DGraphTMsoftware to setup sample rate(from 10 seconds to 12 hours), high/low alarm limit and start/stop method , and download data to PC, etc. And then user can view, analyse and print the data, or export other file formats(txt, xsl, csv, bmp, jpg). Especially, for some professional applications, user can set access password, name each channel, enable/disable specified channel, input calibration data for each channel, disable LED indication for saving power, and select sample mode(Instant, Average, Maximum and Minimum), etc. BENEFITS Portable, precise, compact and low cost Easy to log and analyse data Unique and uniform PC software DGraphTM can meet your higher requirements Elaborate design make it perfectly work in more application field Strict design ensure long term reliable work Enhanced electrostatic protection design to prevent unexpected damage Each unit have single serial number identified by DGraphTMsoftware to manage data simply All data from different data logger and all different measurement parameters can be graphed and analysed together FEATURES USB interface directly communicate with PC for setup and data download User can set access password for data logger User can name each channel and enable/disable specified channel freely LED alarm enable/disable, LED alarm hold enable/ disable and alarm limit settings for all channels via DGraphTM User can input formula to customize compound graph from selected logging data User can create and customize new unit easily and freely for all measurement parameters Logging status indication via red/green LED and battery status indication via yellow LED Start logging method: Immediately, Button, Delayed User can input two point calibration value for each channel when setup Dew point calculated via software DGraphTM IP66 environmental protection Long battery life: Approx. 4 Years @ 10 Minute Sample Rate Replaceable lithium battery and logged data are not lost if battery exhausted SPECIFICATIONS: Relative Humidity Measurement range 0~100%RH Accuracy(Typ.) ± 3%RH Resolution 0.1%RH typically Long Term Drift <0.5%RH per year Temperature Measurement range -35~80C(-31~176F) Accuracy(Typ.)Figure 2 ± 0.3C(± 0.5F) Resolution 0.1°C / 0.2°F Long Term Drift Negligible General Number of Channels Double Channels (One for humidity and the other for temperature) User can enable/disable any channels when setup via DGraphTM Memory Capacity 64KBytes(Total 32,000 readings for all channels) Sample Rate Can be selected from 10 seconds to 12 hours Start Method Immediately, Start by button, and Start at date&time Stop Method Stop when memory full, overwrite when memory full, and stop until specified number of sample points finished Sample Mode Instant(default), average, maximum and minimum This will decide how to dispose data at idle time between a sample interval Button Software config to start logging bybutton, or clear and reset LED alarm when LED alarm is hold LED Red&green LED: Logger Status indication(Include Delay to Start, Logging, Alarm, Finished) (Sofware can disable this two LED for saving power) Yellow LED: Low battery indication Alarm User programmable high or low alarm limit for each channel(If necessary) LED alarm and hold Communication Direct USB connection Need to install the driver provided on CD PC Software DGraphTM software and USB driver required (Included on CD) (Compatible with Windows XP, Windows Vista, Windows 7&8(32 bit & 64bit Versions)) Use these software to setup, download, view graph and analyse data Power Supply User replaceable 1/2AA 3.6V Lithium Battery 1200mAh NOTE: USB interface can supply power directly if necessary Battery Life Approx. 2 Years @ 1 Minute Sample Rate Approx. 4 Years @ 10 Minute Sample Rate Approx. 8 Years without any sample task NOTE: It also Depends on ambient temperatures and using of LEDs Operating Range 0 to 100%RH -35 to 80C(-31 to 176F) Storage Range Recommended: 20 to 60%RH 10 to 50C(50 to 122F) Case Material ABS, TPU, PC Dimentions 123mmX 37mmX 23mm(4.8"X 1.5"X 0.9") Weight Approx. 90 grams(3.19 oz) Mounting Mounting bracket (Optional) or locking eyelet Standard Compliance IP66 Note: we'll ship this item via Epacket to US, usually the delivery time is about 2-3 weeks; for other countries, we'll ship it via registered air mail of Post, usually the delivery time is about 40-50 days. If you want express mail service, please contact us for extra postage in advance.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	BTH01
Country of Manufacture	China
MPN	BTH01
Country/Region of Manufacture	China
