Two Dpdt Signal Relays Module Board, 5v, For 8051 Pic

US $190

  • Hong Kong, Hong Kong
  • Jan 29th
Open on mobile:
QR code
Description April 21 2012, upgraded to TAKAMISAWA relays. 1 Piece Two DPDT Signal Relays Module Board. This item has been assembled, and electrical test passed. Japan FUJITSU TAKAMISAWA high quality signal relay, FR-4 Fiber glass PCB, darlington transistor driving relay, LED indicator for each relay action. Size: 50 x 50 x 16 mm (approximately 2 x 2 x 0.64 inch), PCB thickness: 1.6mm. Power Supply: 5V DC / 100mA (all relays ON). Input control signal voltage:                      0V - 0.5V Low stage (relay is OFF),                      0.5V – 2.5V (unknown state).                      2.5V - 24V High state (relay is ON). Input control signal high state current:                      2.5V: 0.1mA                      5V: 0.35mA                      12V: 1.1mA                      20V: 1.9mA Relay: FUJITSU TAKAMISAWA RY5W-K signal relay. Contact Material: Gold Overlay Silver-Palladium. Datasheet: http://www.fujitsu.com/downloads/MICRO/fcai/relays/ry.pdf Specification: http://www.audiowind.com/pdf/D-122-1V1.pdf, No paper specifications, please download this document. Schematic: PCB size and wiring diagram: PCB Top and Bottom layer: Engineered for professional eBay sellers!
