Twta Ku Nec 100watt 14-14.5ghz Guaranteed

US $2,150.00

Nowra, NSW, Australia
Jan 29th

Open on mobile:
QR code

Up for sale is this NEC, 100 Watt, Ku band TWTA complete with power supply and interconnecting cables. This equipment was removed from a TV broadcast station where it was used for uplinking program via a 6.5 meter dish. The power used in this application was around 5 watts, well below the design power of 100 watts with a 3dB backoff for -26dBc spectral regrowth. The internal TWT is in as new state with only 1.25mA helix current and 150mA cathode current. Requires approx. -20 to -15dBm drive level. Operation is very simple with illuminated membrane switches on the power supply to select LV & heater on and a second switch to select HV on after a preset warm up delay. It is not possible to select HV on until the warm up delay has expired. RF output is controlled via a vernier dial on the RF unit and the actual power is displayed on a meter on the RF unit. RF power is available on the rear of the RF unit via a WR75 waveguide flange. A sample of the RF output is available on the front panel of the RF unit via a SMA female connector. The sample output level is -50dBc The RF unit and power supply has been thoroughly serviced cleaned and checked for correct operation and is guaranteed operational. The unit has been fully tested into a load for quite a few hours without any problems I have a matching NEC Ku band linearizer available for sale also.( see my other items) Using the linearizer, an output power of 75 watts for -26dBc can be achieved. Shipping weight for RF unit & power supply is 48Kg. There will be a $80 packaging charge for this auction and the equipment will be professionally packaged. I can ship internationally using your preferred forwarder or if no preference will use TNT international. I will charge only what it costs to ship. Buyers are welcome to contact me with questions or for shipping quotes. Mobile 0428 863428 or sales@rflab.com.au NOTE** This item is also listed on the eBay Australia site as a separate listing and as such, availability would be subject to possible prior sale.

Condition:

Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...

Brand

NEC
