Ublox M8n Gps Compatible Dji Naza Lite V1/v2 Flight Controller+stand Holder

US $1000

Shenzhen, China
May 28th

Open on mobile:
QR code

Ublox NEO-M8N GPS & Compass Support DJI Naza-M V2/Lite Flight Controller Compatible with DJI Phantom1/2 Description: Ublox NEO-M8N GPS & Compass Support DJI Naza-M V2/Lite Flight Controller Compatible with DJI Phantom1/2 - Support DJI Naza-M and Naza-M V2 flight controller, and it is compatible with DJI Phantom 1/2. Adopting U-Blox the eighth GPS modules NEO-M8N GPS - NEO-M8N has low consumption high precision, limiting precision 0.6m, most are about 0.9m according to tests - Compared to NEO-7N 1.4-1.6m, the precision has been greatly improved, and support GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1 Specification: - Receiver type 72-channel u-blox M8 engine - GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1 - SBAS L1 C/A: WAAS, EGNOS, MSAS - Galileo-ready E1B/C (NEO-M8N) - Nav. update rate1 Single GNSS: up to 18 HZ - Concurrent GNSS: up to 10 Hz - Position accuracy2 2.0 m CEP - Acquisition2 Cold starts: 26 s - Aided starts: 2 s - Reacquisition: 1.5 s - Sensitivity2 Tracking & Nav: –167 dBm - Cold starts: –148 dBm - Hot starts: –156 dBm - Assistance AssistNow GNSS Online - AssistNow GNSS Offline (up to 35 days)3 - AssistNow Autonomous (up to 6 days) - OMA SUPL & 3GPP compliant - Oscillator TCXO (NEO-M8N/Q), - Crystal (NEO-M8M) - RTC crystal Built-In - Noise figure On-chip LNA (NEO-M8M). Extra LNA for - lowest noise figure (NEO-M8N/Q) - Anti jamming Active CW detection and removal. Extra - onboard SAW band pass filter (NEO-M8N/Q) - Memory ROM (NEO-M8M/Q) or Flash (NEO-M8N) - Supported antennas Active and passive - Odometer Travelled distance - Data-logger For position, velocity, and time (NEO-M8N) - Operating temp. –40° C to 85° C - Storage temp. –40° C to 85° C (NEO-M8N/Q) - –40° C to 105° C (NEO-M8M) - RoHS compliant (lead-free) - Qualification according to ISO 16750 - Manufactured and fully tested in ISO/TS 16949 certified production sites - Uses u-blox M8 chips qualified according to AEC-Q100 - Supply voltage 1.65 V to 3.6 V (NEO-M8M) - 2.7 V to 3.6 V (NEO-M8N/Q) - Power consumption4 23 mA @ 3.0 V (continuous) - 5 mA @ 3.0 V Power Save Mode - (1 Hz, GPS mode only) - Backup Supply 1.4 to 3.6 V - NEO-M8N-0 u-blox M8 Concurrent GNSS LCC Module, - TCXO, flash, SAW, LNA, - Timepulse Configurable 0.25 Hz to 10 MHz Features: - Add LAN+SWA to GPS module, with complete sheilding to prevent outer interference. - Add second LAN+SWA to outer GPS module, furtherly enhance the SNR of GPS, ensure the speed and stability of satellite searching. - With working status indicator (Red LED) and GPS positioning indicators (Blue LED). - Adopts imported MOLEX PITCH More Details : - Dimension: 50*50*12.8mm (W*L*H) - Weight: 26.5g (with cables) - Cables: 30cm soft silicone cable - Compatible with NAZA Lite V1, V2, Phantom 1, Phantom 2. Note: This GPS adopts DJI CAN protocol, can not be used as ordinary GPS. Package Include: - 1 x Ublox NEO-M8N GPS for Naza-M V2/Lite Flight Controller Shipping & Payment: Here Offer 100% Satifiation Service,Inlucde re-send item&refund payment; All items here offer 1 year warranty It is not my Duty for Custom Tax All items will be shipped via int'l air mail( no tracking number for items under $65), the time normally takes 7-15 business days. may be later arrivel if the item is checked by custom; We only accept paypal payment.
