Udb1202s 2mhz With Frequency Sweep Function Dds Signal Generator Source

US $2200

CN, China
Jun 7th

Open on mobile:
QR code

Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Description: Model Number:2MHz UDB1202S siganal generator Output waveforms:Sine wave, Square wave and Triangle wave and 2saw tooth wave Output impedance:50Ω+/=10%(signal output) DC offset:+/=2.5V(no load) Display:LCD1602 Frequency range:0.01Hz ~ 2MHz(UDB1202S) Resolution:0.01Hz(10MHz) Sine wave distortion:<=0.8% (reference frequency is 1kHz) Trinagle linearity:>=98% (0.01Hz-10kHz) Rise and fall time of square wave:<=100ns Square Wave Duty range:1%-99%(digital control mode) Product Description Introduction of the instrument UDB12xxS series direct digital synthesis signal generator use DDS technology and FPGA design with the characters of high stability and low distortion ect., with the function of TTL output and 60MHz frequency meter,UDB100xS series have sweep function, the start and end frequency and sweep time can be set at will. It’s the ideal equipment of electronic engineer, laboratory, production lines, the teaching and scientific research. Main technology data 1.Signal Output function Output amplitude >=9Vp-p (signal output,no load)(MAX) About 0.1Vp-p(MIN) Output impedance 50 omega +/-10%(signal output) DC offset +/-2.5V(no load) Display LCD1602 Frequency range 0.01Hz - 2MHz(UDB1202) 0.01Hz - 3MHz(UDB1203) 0.01Hz - 5MHz(UDB1205) 0.01Hz - 10MHz(UDB1210) Resolution 0.01Hz(10mHz) Frequency Stability +/-1x10-6 Frequency accuracy +/-5x0-6 Sine wave distortion <=0.8%(reference frequency is 1kHz) Trinagle linearity >=98%(0.01Hz-10kHz) Rise and fall time of square wave <=100ns Square Wave Duty range 1%-99%(digital control mode) 2.TTL Output function Frequency range 0.01Hz - 2MHz(UDB1202S) 0.01Hz - 3MHz(UDB1203S) 0.01Hz - 5MHz(UDB1205S) 0.01Hz - 10MHz(UDB1210S) Amplitude >3Vp-p Fan Out >20 TTL loads 3.COUNTER function Counter Range 0-4294967295 Frequency Meter Range 1Hz-60MHz Input Voltage Range 0.5Vp-p -20Vp-p 4.ADC function Voltage measurement range 0 - 5V Resolution ratio 0.001V(1mV) Accuracy +/-0.5% 5.SWEEP function(as for UDB100xS series) Frequency range fM1 to fM2 Sweep time 1s-99s 6.Others function Save and Load Parameter M0-M9(M0:default load) Notice for Shipping Country Shipping time by registered air mail/e-packate Shipping time by ems/dhl/fedex express shipping United states 5-15 working days 3-7 working days (ems recommended) Japan, South Korea 5-10 working days 3-5 working days (ems recommended) United Kingdom, Canada, Germany, Austrian, Holland, Czech, and countries in EU 15-25 working days 5-7 working days (ems recommended) Spain, Russian, Italy, France, Mexico, Malaysia, India, South Africa, and countries in America and Asian. 15-55 working days, ( shipping time may delayed by post and customs inspection. 5-15 working days ( only EMS to Russian)
