Udb1308s 8mhz With Frequency Sweep Two Channel Dds Function Signal Generator

US $59.99

Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

WELCOME TO MY SHOP MADE WHOLESALES !!! Item specifics is_customized:YesModel Number:8MHz UDB1308Ssiganal generator Output Sine wave, Square wave and Triangle wave and saw tooth waveOutput impedance:50I©+/=10%DC offset:+/=2.5V(no load)Display:LCD1602Frequency range:0.01Hz ~ 8MHz(UDB1308S)Resolution:0.01Hz(10MHz)Sine wave distortion:<=0.8% (reference frequency is 1kHz)Trinagle linearity:>=98% (0.01Hz-10kHz)Rise and fall time of square <=100nsSquare Wave Duty range:1%-99%(digital control mode) In UDB130x(S) series,we have three moels as following: 1.UDB1302S 2MHz with frequency sweep functon 2.UDB1305S 5MHz with frequency sweep functon 3.UDB1308S 8MHz with frequency sweep functon This product is UDB1308S 8MHz. Introduction of the instrument UDB130xS series direct digital synthesis signal generator use DDS technology and FPGA design with the characters of high stability and low distortion ect,A,B two channel output, two channel TTL output, 60MHz frequency meter,counter function, have sweep function, the start and end frequency and sweep time can be set at will. It?s the ideal equipment of electronic engineer,laboratory, production lines,the teaching and scientific research. Main technology data 1.Signal Output function Output amplitude >=9Vp-p (signal output,no load)(MAX) About 0.1Vp-p(MIN) Output impedance 50 omega +/-10% DC offset +/-2.5V(no load) Display LCD1602 Frequency range 0.01Hz - 2MHz(UDB1302) 0.01Hz - 5MHz(UDB1305) 0.01Hz - 8MHz(UDB1308) Resolution 0.01Hz(10mHz) Frequency Stability +/-1x10-6 Frequency accuracy +/-5x0-6 Sine wave distortion <=0.8%(reference frequency is 1kHz) Trinagle linearity >=98%(0.01Hz-10kHz) Rise and fall time of square wave <=100ns Square Wave Duty range 1%-99% 2.TTL Output function Frequency range 0.01Hz - 2MHz( UDB1302S) 0.01Hz - 5MHz( UDB1305S) 0.01Hz - 8MHz( UDB1308S) Amplitude >3Vp-p Fan Out >20 TTL loads 3.COUNTER function Counter Range 0-4294967295 Frequency Meter Range 1Hz-60MHz Input Voltage Range 0.5Vp-p -20Vp-p 4.SWEEP function(as for UDB100xS series) Frequency range fM1 to fM2 Sweep time 1s-99s 5.Others function Save and Load Parameter M0-M9(M0:default load) 1. DC5V Power input 2. Power switch 3. A channel offset regulation 4. B channel offset regulation 5. B channel amplitude regulation 6. A channel amplitude regulation 7. Signal output terminal 8. Encoder adjusting 9. User key 10. A,B channel indicator light 11. A,B channel switch key 12. LCD display Contact Us Please contact us via TM, Email OR leave message Please don't hesitate to contact us if you have any questions and idea Goods Return/Refund 1 All of our products have been checked and packaged in a good condition before post out 2 Please note that men made defects are not guaranteed, such as damage after incorrect use and so on 3 If you wish to exchange defective items, please note the following steps 4 Step 1) Contact us within 3 days after received the goods 5 Step 2) Send photos OR video to us to show the problem of the items 6 Step 3) Return the items within 3 days with tracking number after contacted us 7 Buyer should pay the shipping fees incurred for exchange 8 The items returned should be kept in their original status 9 We accept all reasonable refunds such as out of stock after payment, but not recommend 10 All customers should contact us for seeking a better solution before asking refund Feedback 1 Positive feedback "5-Star" is very important to us, we sincerely invite you to leave Positive Feedback “5-Star” if you are satisfied with our product and service 2 Please contact us before leaving any Neutral (3 Stars) or Negative (1-2 Stars) feedbacks. 3 We will try our best to work with you to solve the problem 4 We will leave a "5-Star" feedback for all customers after confirmed payment Attention 1 All dear customers please leave your FULL NAME and confirmed address when you make order, it can avoid parcel returning back to China, especially Russian buyers. 2 China Post Delivery time: Russian-30-90days; USA-20-60days; UK-20-60days; UA-30-90days; CA-30-60days; SPAIN-30-60days; FR-30-60days; SWDEN-30-60days; BRAZIL-30-70days 3 Dear customers usually cannot track the parcel within 7days after the parcel sent out, even some time cannot be tracked before it arrived your country customs 4 No tracking information for more than 7 days, not represent the parcel does not move, please wait patiently and contact us at anytime THANK YOU !

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Model	1308S
