Uhf Rfid Active Non-directional 5 Meters Middle Range Integrated Reader & Writer

US $195.99

HongKong, China
Jan 30th

Open on mobile:
QR code

SD-7120 passive middle range integrated reader Product Parameters: Working Frequency: 902~928MHz or 865~868MHz or customized Reading Distance: reliable reading distance 3~5m, max.8m(adjustable) Product Size: 250x250x40mm Working Voltage: DC-12V+-2V Max. Power Consumption: 5W Working Temp.: -35 degree C~+65 degree C Storage Temp.: -45 degree C~+95 degree C Protocols Supporting: ISO-18000-6C(EPC G2),ISO-18000-6B(optional) Antenna Plus: 8dbi circular polarization Antenna Power: connecting antenna power 0.5W(adjustable) Data Interface: Wiegand26/34/42, 10/100M self-adaptable Ethernet(need customize), RS232, RS485 data interface; leave external triggering signal connecting port in advance Fast Identification: can identify fast-moving tags that moving speed is more than 120km/h Working Hint: buzzer Package Weight: 2.0Kg Accessories: 1set adjustable installing bracket; 1pc 12V power supply; 1pc power supply wire Product Features: Reliable reading range can reach upto 5m Compatible 6C and 6B agreement Support multiple language SDK package, system connecting is convinient Can customize RJ45 interface Integrative industrial design, water-proof, sun-defending, convenient installation Applying Fields: Vehicle Intelligent Management: car parking lot, speed way non-stop toll, customs using, weighing automatically, etc. Production Flew-line Intelligent Management: intelligent sorting of products on flew-line, etc. Warehouse Management: cargoes in and out automatic recording, etc. Logistics management: container management, tray management, asset tracking, etc. People management: in and out management at school gate, in and out management at factory gate, etc. User Manual FDY series reader usually connect with computer via RS232 data interface,to do data exchanging. Because FDY series reader just can do reading/ writing operation to tags after receiving the controlling order of the controller,we will supply our customers multiple language SDK package, customers can do the development of applying softwre. Working temperature of the readers is: -35 degree C~+65 degree C. Therefore, when use our reader in cold area and season, should notice that open the reader to warm-up 15 minutes in advance before formally using, to make sure normal operation of the reader. We suggest that when testing, there is not any objects to keep out at least 20 meters within the front of the reader; when holding tag, please use fingers to touch the tag brims of two sides, when it is linearization antenna, should hold the tags parallelly or vertically according to the relative polarization direction, to make sure reading effect. When installing height is more than 1.8meters, lean the reader downwards in some sort. Shipping: United States,Canada,Europe and Asia:FedEx shipping Other countres:Singapore Post
