Ultra-Low pressure RO membrane RE2540-BLF Ultra-low pressure RO element 800 GPD, US $198.00 – Picture 0

Ultra-Low pressure RO membrane RE2540-BLF Ultra-low pressure RO element 800 GPD, US $198.00 – Picture 1

Ultra-Low pressure RO membrane RE2540-BLF Ultra-low pressure RO element 800 GPD, US $198.00 – Picture 2

Ultra-low Pressure Ro Membrane Re2540-blf Ultra-low Pressure Ro Element 800 Gpd

US $198.00

Canyon Country, California, United States
Jan 31st

Open on mobile:
QR code

RE2540-BLF Ultra-low pressure RO element for low TDS water SPECIFICATIONS: General Features Permeate flow rate: 800 GPD (3.0 m3/day) Stabilized salt rejection: 99.2% Effective membrane area: 27 ft2 (2.5 m2) 1. The stated product performance is based on data taken after 30 minutes of operation at the following test conditions: • 500 mg/L NaCl solution at 100 psig (0.5 MPa) applied pressure • 15% recovery • 77 oF (25 oC) • pH 6.5–7.0 2. Minimum salt rejection is 99.0%. 3. Permeate flow rate for each element may vary but will be no more than 15%. 4. All elements are vacuum sealed in a polyethylene bag containing 1.0% SBS (sodium bisulfite) solution and individually packaged in a cardboard box. Membrane type: Thin-Film Composite Membrane material: Polyamide (PA) Element configuration: Spiral-Wound, FRP Wrapping Dimensions Model Name A B C D E Part Number Inter-connector Brine Seal RE2540-BLF 40.0 inch (1,016 mm) 2.5 inch (64 mm) 0.75 inch (19.1 mm) 1.1 inch (28 mm) 1.1 inch (28 mm) 40000305 40000223 1. Each membrane element supplied with one brine seal, one interconnector (coupler) and four o-rings. 2. All RE2540 elements fit nominal 2.5 inch (64 mm) I.D. pressure vessels. The information provided in this document is solely for informative purposes. It is the user’s responsibility to ensure the appropriate usage of this product. Woongjin Chemical assumes no obligation, liability or damages incurred for the misuse of the product or for the information provided in this document. This document does not express or implies any warranty as to the merchantability or fitness of the product. RE2540-BLF Ultra-low pressure RO element for low TDS water 800 GPD-CSM General Features Permeate flow rate: 800 GPD (3.0 m3/day) Stabilized salt rejection: 99.2% Effective membrane area: 27 ft2 (2.5 m2) 1. The stated product performance is based on data taken after 30 minutes of operation at the following test conditions: • 500 mg/L NaCl solution at 100 psig (0.5 MPa) applied pressure • 15% recovery • 77 oF (25 oC) • pH 6.5–7.02. Minimum salt rejection is 99.0%. 3. Permeate flow rate for each element may vary but will be no more than 15%.4. All elements are vacuum sealed in a polyethylene bag containing 1.0% SBS (sodium bisulfite) solution and individually packaged in a cardboard box. Membrane type: Thin-Film CompositeMembrane material: Polyamide (PA)Element configuration: Spiral-Wound, FRP Wrapping FOR MORE INFORMATION SEE THIS http://www.csmfilter.com/upload/csm/swe/prod1_201251411466.pdf

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	CSM
Country/Region of Manufacture	Korea, Republic of
Model	RE2540 BLF
low pressure ro membrane	ro membrane
MPN	BAAJE1213147
BAAJE1213147	CSM
