Ultrasonic Flow Meter, Dc Pnp/npn, Quick Disconnect, 2 Outputs, Ifm Su7001

US $525.00

Fort Collins, Colorado, United States
Jan 30th

Open on mobile:
QR code

IFM ELECTRONIC SU7001 FLOW SENSOR WITH DISPLAY, MAGNETIC INDUCTIVE, 0-13.22 GPM, DUAL OUTPUTS, 14-176DEG. F OPERATING RANGE Ultrasonic flow meter, DC PNP/NPN, Function programmable, Totalizer function, 2 outputs, OUT1 = flow monitoring (binary), flow rate meter (pulse), preset meter (binary), OUT2 = flow monitoring or temperature monitoring (analog or binary), Input for counter reset, Measuring range, 0...13.22 gpm, 14...176 °F, Maximum permissible flow rate, 15.86 gpm (951 gph), connection to pipe by means of an adapter, Quick disconnect, 4-digit alphanumeric display Application: Liquids of the fluid group 2 according to Article 9 of the Pressure Equipment Directive (PED): , water, glycol solutions, oils , (low-viscosity oils with viscosity 7...40 mm?/s at 40°C; , high-viscosity oils with viscosity 30...68 mm?/s at 40°C) Operating voltage: 19...30 V DC Electrical design: DC PNP/NPN Output function: OUT1: normally open / closed programmable or pulse, OUT2: normally open / closed programmable or analog (4...20 mA / 0...10 V, scaleable) Process connection: G 3/4 flat seal Current rating: 2 x 250 mA Flow monitoring: Measuring range: 0.00...13.22 gpm; 0...793 gph Temperature monitoring: Measuring range: 14.0...176.0 [°F] Pressure rating: 232 [psi] Connection: M12 connector Housing materials: housing: AlMgSi0.5 anodized; sealing: Viton; connector housing: brass Optalloy-plated; PA 6.6; cover film: polyamide Materials (wetted parts): stainless steel 316L / 1.4404; Viton; PES; Centellen 200 Medium temperature: 14...176 °F Ambient temperature: 14...140 °F Protection: IP 67 Display: Display unit: 5 x LED green (gpm, gph, gal, °F, 10?) ; Switching status: 2 x LED yellow ; Measured values: 4-digit alphanumeric display ; Programming: 4-digit alphanumeric display Accessories (to be ordered separately): Socket, Mounting accessories Brand: ifm electronic gmbh or equivalent Type: SU7001 CLICK HERE TO GET THE FULL SPECS SHIPPING: We offer FREE domestic shipping; and international shipping provided by the EBAY Global Shipping program. RETURNS: Vacuum Coating Surplus offers exchanges for up to 30 days after receipt of the item. Please note: return and exchange shipping are the buyer’s responsibility. Check out our other EBAY products. IPN: 30175

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ifm electronic
MPN	SUR34EGRFRKG/W/US-100-PF
Model	SU7001
Country/Region of Manufacture	Germany
