Umts W-cdma Air Protocol Analyzer Yokogawa Abit Ap-4000

US $9,999.00

Altenrhein, Switzerland
Jan 29th

Open on mobile:
QR code

UMTS WCDMA W-CDMA AIR PROTOCOL ANALYZER AKA 3G-CELLULAR SNIFFER THIS IS EX LAW ENFORCEMENT EQUIPMENT COMES COMPLETE WITH IBM-LAPTOP AND INSTALLED SOFTWARE; 2 ANTENNAS ON SALE NOW ! Descriptions: Applicable Standard 3GPP UTRA/FDD Release-99 RRC version: 2003-03 Radio Frequency UL: 1920-1980 MHz DL: 2110-2170 MHz Channel bandwidth: 5 MHz/carrier Channel Interval: 200 KHz Modulation scheme DL: QPSK modulation/QPSK spreading UL: BPSK modulation/HPSK spreading (OCQPSK) Number of RF system 2 unit, independent frequency setting is possible Reference Physical channel P-SCH, S-SCH, P-CPICH Multipath signal RAKE receiver for S-CCPCH and DL DPCH Supported Physical channel DL: P-CCPCH, S-CCPCH, AICH, PICH, DPCH UL: PRACH, DLPCH Number of decoders DL: 2xP-CCPCH, 2xS-CCPCH,2xAICH,2xPICH,6xDPCH UL: 2xPRACH,4xDPCH Transmit diversity STTD, TSTD Closed loop mode Compressed mode for Inter-Frequency Handover measurement, GSM measuremen Supported physical channel bitrate 30 kbps to 960 kbps Supported transport channel number up to 5 transport channel/DPCH, up to 3 transport channel/SCCPCH Supported coding scheme 1/2 convolutional, 1/3 convolutional, turbo Supported CRC size 0,8,12,16,24 bit Supported TTI 10,20,40 ms Maxium transport channel bitrate DL: 384 kbps UL: 384 kbps Radio Link numbers for SHO up to 6 RL for SHO observation mode, up to 3RL for Inter-Frequency observation mode Handover Soft-handover, Softer-handover, intra-frequency handover, inter-frequency handover Cell search function SCH profile graph, SCH search for all frequency, scrambling code search Real time monitor function RRC message, CRC status for transport channel Store Transport channel data, Physical channel control field data, signal power Offline analysis Physical layer: RSSI/RSCP/Control field of physical channel Transport layer: CRC status/transport block data MAC layer: Header analysis RLC layer: Header analysis, SEQ and acknowledge analysis for AM mode C-Plane Offline analysis RRC: RRC ASN.1 display NAS: CC/MM/GMM/SM/RRM analysis display SMS analysis display U-Plane Offline analysis Packet on PS: TCP/IP header analysis, PCAP format save (optional) For german speaking customers: Der als einziger weltweit zur Verfugung stehender W-CDMA Air Protocol Analyzer dieser Art, der AP-4000, erfasst und decodiert der Analysator Signale zwischen BTS (Base Transceiver Station) und UE (User Equipment) und bietet Hilfe fur diejenigen, die Basisstationen und / oder UEs entwickeln, Protokollsoftware programmieren oder fur InterOperabilityTests (IOTs) verantwortlich sind. Der AP-4000 kann den Verbindungsaufbau in Echtzeit aufzeichnen, dabei ist es unerheblich, von welchem Hersteller die Basisstation bzw. UE sind. Anhand der Datendecodierung bis hin zu den hoheren Schichten (RLC, RRC) sowie einer detaillierten Anzeige der Analyseergebnisse auf einem vorkonfigurierten PC (mitgeliefert), ist der AP-4000 hervorragend fur das Prufen der spezifizierten Testablaufe (3GPP/W-CDMA Testprozeduren) geeignet. Das Gerat unterstutzt das 3GPP Release 99 und ist sowohl fur den Laboreinsatz (BTS/UE Test, Protokoll Software Debugging) als auch fur Feldmessaufgaben (BTS/UE Field Test) geeignet. --- terms and conditions --- This item is fully functional and intended for reuse. If you have any questions about this item, please email through the eBay system prior to bidding and/or purchasing. The item exteriors may have minor scratches, scuffs, dents, cracks, etc. If any of these defects are considered major, or would affect any functions of the unit, they will be described in detail of this auction description. Important: Import duties, taxes and charges are NOT included in the item price or shipping charges. These charges are solely the buyer’s responsibility. The buyer is also reponsible to hold or get any necessary permit or licenses to import and/or use this item. Please check with your country’s customs office to determine what these additional fees will be prior to bidding/buying. Purchaser may not revoke its acceptance for any reason, if the item has to be re-stocked, a fee of 35% from the total will be charged and is non refundable.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Manufacturer	YOKOGAWA ABIT
ABIT (YOKOGAWA)	AP-4000
