Uni-t Ut181a Digital Multimeter

US $373.00

HK, Hong Kong
Jan 29th

Open on mobile:
QR code

UNI-T UT181A is a True RMS multimeter which measures AC/DC voltage and current, resistance, admittance, capacitance, frequency, temperature, duty cycle, pulse width and can be used for continuity and diode tests. Features True RMS measurements Data recorder 60000 digit 3.5-inch color LCD with backlight. Functions: AC/DC current and voltage resistance capacitance admittance frequency temperature (?C and ?F) duty cycle pulse width continuity test (with buzzer) diode test Auto ranging Relative measurements Max/Min measurements Data Hold function Peak Hold function Fused 10A range Auto power off Low battery indication Technical Specifications Display 3.5-inch color TFT LCD (320 x 240) DC voltage Range 60 mV / 600 mV / 6 V / 60 V / 600 V / 1000 V Accuracy ±(0.025%+5) AC voltage Range 60 mV / 600 mV / 6 V / 60 V / 600 V / 1000 V Accuracy ±(0.3%+30) DC current Range 600 ?A / 6000 ?A / 60 mA / 600 mA / 10 A Accuracy ±(0.08%+10) AC current Range 600 ?A / 6000 ?A / 60 mA / 600 mA / 10 A Accuracy ±(0.6%+20) Resistance Range 600 ? / 6 k? / 60 k? / 600 k? / 6 M? / 60 M? Accuracy ±(0.05%+2) Admittance Range 60 nS Accuracy ±(2%+10) Capacitance Range 6 nF / 60 nF / 600 nF / 6 ?F / 60 ?F / 600 ?F / 6 mF / 60 mF Accuracy ±(2%+5) Frequency Range 10 Hz - 60 MHz Accuracy ±(0.01%+5) Temperature, ?C Range -40 ~ 1000 Accuracy ±(1%+30) Temperature, ?F Range 40 ~ 1832 Accuracy ±(1.5%+50) Duty cycle 10% ~ 90% Power 7.4 V, 3000 mAh, Li-ion battery Dimensions 103 x 225 x 59 mm Weight 638 g Package Contents Multimeter UNI-T UT181A (1 pc.) Temperature probe (2 pcs.) Test lead (1 pair) USB cable (1 pc.) CD with software (1 pc.) Battery (1 pc.) Power adapter (1 pc.) User manual (1 pc.)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	UNI-T
Frequency	up to 60 MHz
Model	1181A (UT181A)
DC	up to 10 A
Country/Region of Manufacture	China
AC	up to 10 A
Warranty	24
Inductance	no
DC Voltage	up to 1000 V
Temperature	yes
AC Voltage	up to 1000 V
Power	no
Resistance	up to 60 MOhm
Duty cycle	yes
Capacitance	up to 60 000 ?F
