Uni-t Ut58d Digital Multimeter

US $53.00

  • HK, Hong Kong
  • Jan 29th
This digital multimeter measures AC/DC current and voltage, resistance, capacitance, inductance, and tests diodes, continuity and transistors. Features Functions: AC/DC current and voltage resistance capacitance inductance continuity test (with buzzer) diode test transistor test Data Hold function Manual ranging Sleep mode Low battery indication Comparative Specifications Model UT58D UT58E Display LCD 60 x 54 mm, max. 1999 LCD 60 x 54 mm, max. 19999 DC voltage, V 200mV/20V/200V/1000V ±(0.5%+1) 200mV/2V/20V/200V/1000V ±(0.05%+3) AC voltage, V 2V/200V/1000V ±(0.8%+3) 2V/20V/200V/1000V ±(0.5%+10) DC current, A 2mA/200mA/20A ±(0.8%+1) 2mA/200mA/20A ±(0.5%+5) AC current, A 2mA/200mA/20A ±(1%+3) 20mA/200mA/20A ±(0.8%+10) Resistance, ? 200?/2k?/200k?/2M?/20M? ±(0.8%+1) 200?/2k?/20k?/2M?/200M? ±(0.5%+10) Capacitance, F 20nF/200nF/2µF/100µF ±(2.5%+5) 2nF/20nF/2µF/20µF ±(3%+40) Frequency, Hz - 20kHz ±(1.5%+5) Inductance, H 2mH/20mH/200mH/20H ±(2%+10) - Temperature, ?C - -40?C ~ 1000?C ±(1%+30) Sampling rate 2-3x/s Power 9V battery: NEDA 1604, 6F22 or 006P Dimensions, (H x W x D) mm 179 x 88 x 39 Weight, g kg 351 Package Contents Multimeter UT58D Test lead Test clip Battery Multi-purpose socket User manual
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand UNI-T
Frequency does not measure the frequency
Model UTM 158D (UT58D)
DC up to 20 A
Country/Region of Manufacture China
AC up to 20 A
Warranty 24
Inductance yes
DC Voltage up to 1000 V
Temperature no
AC Voltage up to 1000 V
Power no
Resistance up to 20 MOhm
Duty cycle no
Capacitance up to 100 ?F
