Uni-t Ut61d Digital Multimeter

US $74.00

HK, Hong Kong
Jan 29th

Open on mobile:
QR code

UNI-T UT61D Digital Multimeter is a high-quality multifunction pocket digital multimeter. This convenient portable device is powered from a 9 V battery. UNI-T UT61D is characterized by multiple measurements (voltage, current, resistance, capacitance, frequency, temperature) and tests (diode, transistor, continuity) and auto power-off function, analog bar graph, data hold function. UNI-T UT61D Digital Multimeter Features Compact and lightweight pocket-size device. LCD display with backlight. Data hold function. Analog bar graph. Auto/manual ranging. Max/Min mode. Relative measurements mode (REL). Multiple measurements: AC Voltage. DC Voltage. AC Current. DC Current. Resistance. Capacitance. Frequency. Diode testing. Continuity test. Sleep mode. Continuity buzzer. Battery power. Interface: RS232, USB. Tilt back stand. Easy to connect and operate. Electrical safety: EN61010-1, CATII600V/CATI1000V. UNI-T UT61D Digital Multimeter Technical Specifications Function Range Accuracy DC Voltage 60 mV/600 mV/6 V/60 V/600 V/1000 V ±(0.5%+1) AC Voltage 60 mV/600 mV/6 V/60 V/600 V/750 V ±(1.0%+3) DC Current 600 mA/6000 mA/60 mA/600 mA/6 A/10 A ±(1.0%+3) AC Current 600 mA/6000 mA/60 mA/600 mA/6 A/10 A ±(1.2%+5) Resistance 600 ?/6 k?/60 k?/600 k?/6 M?/60 M? ±(1.0%+2) Capacitance 40 nF/400 nF/4 ?F/40 ?F/400 ?F/4000 ?F ±(3.0%+5) Frequency 10 Hz - 10 MHz ±(0.1%+4) Frequency Response 45 Hz ~ 3 kHz Duty Cycle 0.1% ~ 99.9% Imput Impedance for DC Voltage Measurement ~ 10 M? General Characteristics Power 9 V Battery (6F22) Display LCD, 43 x 65 mm Size 180 x 87 x 47 mm Weight 370 g UNI-T UT61D Digital Multimeter Package Contents UNI-T UT61D Digital Multimeter Unit (1 pc.) Test leads (2 pcs.) Multi-purpose socket (1 pc.) Battery (1 pc.) RS232 Interface Cable (1 pc.) CD with Installation Guide & Computer Software (1 pc.) User manual (1 pc.)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	UNI-T
Frequency	up to 10 MHz
Model	UT61D
DC	up to 10 A
Country/Region of Manufacture	China
AC	up to 10 A
Warranty	24
Inductance	no
DC Voltage	up to 1000 V
Temperature	no
AC Voltage	up to 750 V
Power	no
Resistance	up to 60 MOhm
Duty cycle	no
Capacitance	up to 4000 ?F
