Uni-t Utg9020d Dds General Function Signal Universal Waveform Generators 20mhz

US $487.00

shenzhen, China
Jan 29th

Open on mobile:
QR code

[zipedit] Our-Store Home Page About Us Contact Us Add to Favourate Payment Shipping Return Categories Payment Why Us Subscribe NewsLetter Add our store in to your favourites and recieve our exclusive emails about new items and special promotions Subscribe Product Overview Description UNI-T UTG9020D DDS General Function Signal Universal Waveform Generators 20MHz (DC-TE11408) SPECIFICATIONS Feature UTG9020D Waveforms Standard Waveforms Sine, Square, Triangle, Ramp up, Ramp down, Random Noise, SIN (X) / X, Exponential Rise, Exponential Fall, Pulse. Expand up to 36 types of waveform Arbitrary Waveforms Arbitrary Waveform Length 32768 bits Momory Size 4 x 32k Vertical Resolution 14 bits Sample Rate 100 MSa/s Amplitude Characteristics Range (no load) from 1mVp-p to 20Vp-p Accuracy ± 5% (Sine at 1kHz) Resolution 0.01mV Frequency Characteristics Range of Sine from 1?Hz to 20MHz Range of Square from 1?Hz to 5MHz Range of Other Waveforms from 1?Hz to 1MHz Stability 50ppm (from -10°C to 40°C) Resolution 0.1?Hz or 8 digit Accuracy 0.1?Hz (<100Hz), 0.4Hz (>100Hz) Signal Characteristics Harmonic Distortion of Sine <20kHz: -60dBc, 20kHz to 1MHz: -50dBc, 1MHz to 10MHz: -40dBc, 10MHz to 20MHz: -30dBc Square, Pulse Rise/Fall Time <20ns Overshoot <5% Asymmetry 1% + 20ns Duty Cycle of Pulse 0.1% to 99.9% Linearity of Triangle, Ramp <1% Modulation Characteristics Modulation Mode Linear sweep (LIN SWP), logarithmic sweep (LOG SWP), FDK, PSK, ASK, BURST, INF FM, INT PM, INT AM, and external AM (EXT AM) Output Characteristics Output A (Main Output) Output Impedance 50? DC Offset from -100% to 100% Vpeak Output B Waveform All internal waveform Amplitude 200mVp-p to 20Vp-p (no load) Output Impedance 600? Frequency Range 0.1Hz to 20kHz Frequency Counter Frequency Range: 1Hz to 100MHz, Amplitude Range: 100mV to 5V RS-232 Interface 9600Baud, N, 8, 1 GENERAL CHARACTERISTICS Power AC 220V / 50Hz Product Color Red and Grey Product Net Weight 3kgs Product Size 320mm x 240mm x 100mm Standard Accessories BNC to BNC Cable, Power Cord, English Manual Standard Individual Packing Gift Box Standard Quantity Per Carton 6 pcs Standard Carton Measurement 660 x 410 x 600mm (0.16 CBM Per Export Carton) Standard Carton Gross Weight 21kg Payment Shipping 100% Success Refund & Return UNI-T UTG9010C General Function Signal Generator 1HZ-10MHZ 20Vp-p AC 220V (DC-TE11405) Home Page About Us Contact Us Add to Favourate Payment Shipping Return Designed By XDiom Graphics

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	UNI-T
Model	UTG9020D
