Unique New Ua6013l Digital Auto Range Capacitor Capacitance Tester Meter Tool

US $15.22

HongKong, China
Jan 29th

Open on mobile:
QR code

???? 1 eBay Store Categories Feature: 100% brand new and high quality. Quantity: 1 6013L type digital capacitance meter is pocket, convenient operation, accurate numerical reading, low-consumption, driven by battery, and showing numbers in a big LCD. Being accurate in measuring, it covers 9 measuring sections, a wide rang from 0.1pF to 20,000?F. It can be used in testing error testing, numerical analysis, selecting capacitance, measuring unknown capacitance, matching capacitance, and measuring the capacitance of cable, switch and printing electrocircuit. Panel Layout It is applied with CMOS double-bevel A/D convertor that is automatic in zeroing and polar selection, and makes instruction for beyond measuring range. Wide measuring range, covering 9 measuring sections from 0.1pF to 20,000?F that includes nominal value of any capacitance. Biggest display value: 1999(3 1/2). Reading: 2-3 readings/sec. Zeroing: There is a zeroing knob on the front, easy for operation. Data hold: Put the “HOLD” switch to "ON" and the DH sign will appear on the display. Press “” button , the back light will light. Temperature for accurate measuring: 25°C±5°C Temperature range: working temperature: 0°C to 40°C Storage temperature: -10°C to 50°C Relative humidity: <80% Power: a 9V laminated battery Instruction for low voltage of battery: showing“” signal on the left-upper of the LCD. Power Supply: 9V battery (not included) Size: As the picture shows Note: Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you! Specifications: Environment temperature: 25°C±5°C Relative humidity: <80% Rang Accuracy Definition Testing frequency 200pF ±0.5%±20digit 0.1pF 800Hz 2nF ±0.5%±20digit 1pF 800Hz 20nF ±0.5%±20digit 10pF 800Hz 200nF ±0.5%±20digit 0.1?F 800Hz 2?F ±0.5%±20digit 1nF 800Hz 20?F ±0.5%±20digit 10nF 80Hz 200?F ±0.5%±20digit 0.1?F 8Hz 2000?F ±2.0%±20digit 1?F 8Hz 20000?F ±4.0%±20digit 10?F 8Hz Operation: Firstly, check a 9V battery whether its electric voltage is short that will show “” signal on the left-upper of the LCD. Secondly, pay attention to the polarity or the capacitance to be tested. Thirdly, recharge the capacitance before measuring. Select proper measuring section according to the capacitance to be tested. Check and use the zeroing knob on the front of the meter to adjust the value to zero before measuring. Insert the black sensor into the jack with “-”signal and the red sensor into the jack with “+”. Connect the capacitance to be tested with the two sensors. Pay attention to the polarity of the capacitance ! Read capacitance numerical value displayed. Notes: If you don’t know the approximate value of a capacitance, you should select measuring section of 200nF and then make relevant adjusting according to practical situation. If the capacitance is in short circuit, the meter shows “beyond measuring range ”. If the capacitance is in electric leakage, the meter shows “beyond measuring range ”or “much bigger than the normal value ”. If the capacitance is open-circuit, the meter shows “Zero ”or “several pF ”. In testing small capacitance, directly insert the capacitance into the jack instead of using the sensors for better accuracy. Maintenance: The meter is of highly accurate electronic apparatus. Don’t change its internal circuit rashly for no damage to the meter. Don’t exert electric voltage upon the jack parts of the meter for no damage to the meter. Don’t test the sensors in short circuit , or the battery will be consumed out quickly. Don’t use a meter whose back cover doesn’t cover the meter well. Always replace battery and fuse after taking sensors out of a meter that is switched off. First, screw bolts in the back cover out. Second, take off the back cover. Third, replace battery and fuse according to specification provisioned in the operation manual. Suitable fuse for this meter is 200mA/250V, which external dimension is ?5x20mm. Please take out the battery when not using for a long time. Package Content: 1XNew UA6013L Digital Auto Range Capacitor Capacitance Tester Meter Tool 2XCable 1XEnglish User Manual(NO Retail Box. Packed Safely in Bubble Bag) Note: If you need different color or similar items, please visit my eBay store to find it. Thanks. Shipping: We Ship to Worldwide, except China, Belgium, Luxembourg, Italy, Croatia, Nigeria, Hong Kong, and we do not ship to APO/FPO. Orders processed within 24-48 hours of payment verification. Before buying, Please make sure your paypal and ebay address is correct. Or not, please correct it before payment. We are very sorry we do not support combine postage. If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction! Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery. Delivery Time: Payment: We accept PayPal only. All major credit cards are accepted through secure payment processor PayPal. Payment must be received within 7 business days of auction closing. Please make sure your paypal and ebay address is correct. Or not, please correct it before payment. Warranty and Guarantee: 12 months Manufacturer's Warranty . Buy with confidence! If you are not satisfied when you receive your item, please return it within 30 days for a replacement or money back. Please contact me before you return it. Defective items MUST BE reported and returned to us within the warranty period (and in the original packaging, if possible). You must tell us what the defect is and give us your eBay ID. Return shipping is to be paid by the Buyer. Other Policies: We are not responsible for any custom duty or import tax. We will leave POSITIVE FEEDBACK after receiving the payment. Please contact us if you are not satisfied with the item after receive it. All email will be answered within 1 working day. If you do not receive our reply, please kindly re-sent your email and we will reply to you as soon as possible. You agree to all of the above-listed policies upon bidding on and winning this auction! On Dec-23-14 at 20:05:38 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Type	Capacitance Tester Meter Tool
Brand	Unbranded
